Proline Promass H 300 PROFINET
Parameter
Operating mode
Terminal number
Signal mode
Endress+Hauser
Configuring the frequency output
Navigation
"Setup" menu → Pulse/frequency/switch output
‣
Pulse/frequency/switch output
1 to n
Operating mode
Terminal number
Signal mode
Assign frequency output
Minimum frequency value
Maximum frequency value
Measuring value at minimum
frequency
Measuring value at maximum
frequency
Failure mode
Failure frequency
Invert output signal
Parameter overview with brief description
Prerequisite
–
–
–
Description
Define the output as a pulse,
frequency or switch output.
Shows the terminal numbers
used by the PFS output
module.
Select the signal mode for the
PFS output.
Commissioning
→  103
→  103
→  103
→  104
→  104
→  104
→  105
→  105
→  105
→  105
→  105
Selection / User Factory setting
interface / User
entry
• Pulse Pulse
• Frequency
• Switch
• Not used –
• 24-25 (I/O 2)
• 22-23 (I/O 3)
• Passive Passive
• Active
• Passive NAMUR
103
