Proline Promass H 300 PROFINET
Endress+Hauser
Vibrations
The high oscillation frequency of the measuring tubes ensures that the correct operation of
the measuring system is not influenced by plant vibrations.
6.1.3

Special mounting instructions

Drainability
The measuring tubes can be completely drained and protected against solids build-up in
vertical orientation.
Sanitary compatibility
When installing in hygienic applications, please refer to the information in the
"Certificates and approvals/hygienic compatibility" section .
Zero point adjustment
All measuring devices are calibrated in accordance with state-of-the-art technology.
Calibration takes place under reference conditions→  232. Therefore, a zero point
adjustment in the field is generally not required.
Experience shows that zero point adjustment is advisable only in special cases:
• To achieve maximum measuring accuracy even with low flow rates.
• Under extreme process or operating conditions (e.g. very high process temperatures or
very high-viscosity fluids).
Protective cover
280 (11.0)
146 (5.75)
Cover locking
NOTICE
Order code for "Housing", option L "Cast, stainless": The covers of the transmitter
housing are provided with a borehole to lock the cover.
The cover can be locked using screws and a chain or cable provided by the customer.
It is recommended to use stainless steel cables or chains.
If a protective coating is applied, it is recommended to use a heat shrink tube to protect
the housing paint.
134 (5.3)
255 (10.0)
12 (0.47)
30 (1.18)
Installation
A0029553
25
