Technical data
Version
Tantalum (order code for "Measuring tube
mat.", option EA)
Zirconium 702 (order code for "Measuring
tube mat.", option DA)
Density
Pressure-temperature
ratings
Sensor housing
238
Dependency of ambient temperature on medium temperature
T
a
33
Exemplary representation, values in the table below.
T
Ambient temperature range
a
T
Medium temperature
m
A
Maximum permitted medium temperature T
require a reduced ambient temperature T
B
Maximum permitted ambient temperature T
sensor
Values for devices used in the hazardous area:
Separate Ex documentation (XA) for the device → 250.
Not insulated
A
T
T
a
m
60 °C (140 °F) 150 °C (302 °F) –
60 °C (140 °F) 205 °C (401 °F) –
0 to 5 000 kg/m
3
(0 to 312 lb/cf)
An overview of the pressure-temperature ratings for the process connections is
provided in the "Technical Information" document
The sensor housing is filled with dry nitrogen gas and protects the electronics and
mechanics inside.
If a measuring tube fails (e.g. due to process characteristics like corrosive or abrasive
fluids), the fluid will initially be contained by the sensor housing.
If the sensor is to be purged with gas (gas detection), it should be equipped with purge
connections.
Do not open the purge connections unless the containment can be filled immediately
with a dry, inert gas. Use only low pressure to purge. Maximum pressure:
5 bar (72.5 psi).
Proline Promass H 300 PROFINET
A
at T
= 60 °C (140 °F); higher medium temperatures T
m
a max
a
for the maximum specified medium temperature T
a
Insulated
B
A
T
T
T
T
a
m
a
–
60 °C (140 °F) 110 °C (230 °F) 55 °C (131 °F) 150 °C (302 °F)
–
60 °C (140 °F) 110 °C (230 °F) 50 °C (122 °F) 205 °C (401 °F)
B
T
m
of the
m
B
T
m
a
Endress+Hauser
A0031121
m
T
m
