Commissioning
Parameter
Switch-on value
Switch-off value
Switch-on delay
Switch-off delay
Failure mode
Invert output signal
* Visibility depends on order options or device settings
108
Prerequisite
• The Switch option is
selected in the Operating
mode parameter.
• The Limit option is selected
in the Switch output
function parameter.
• The Switch option is
selected in the Operating
mode parameter.
• The Limit option is selected
in the Switch output
function parameter.
• The Switch option is
selected in the Operating
mode parameter.
• The Limit option is selected
in the Switch output
function parameter.
• The Switch option is
selected in the Operating
mode parameter.
• The Limit option is selected
in the Switch output
function parameter.
–
–

10.5.10 Configuring the relay output

The Relay output wizard guides the user systematically through all the parameters that
have to be set for configuring the relay output.
Navigation
"Setup" menu → Relay output 1 to n
‣
RelaisOutput 1 to n
Switch output function
Assign flow direction check
Assign limit
Assign diagnostic behavior
Assign status
Switch-off value
Description
Enter measured value for the
switch-on point.
Enter measured value for the
switch-off point.
Define delay for the switch-on
of status output.
Define delay for the switch-off
of status output.
Define output behavior in
alarm condition.
Invert the output signal.
Proline Promass H 300 PROFINET
Selection / User Factory setting
interface / User
entry
Signed floating-point Country-specific:
number • 0 kg/h
• 0 lb/min
Signed floating-point Country-specific:
number • 0 kg/h
• 0 lb/min
0.0 to 100.0 s 0.0 s
0.0 to 100.0 s 0.0 s
• Actual status Open
• Open
• Closed
• No No
• Yes
→  109
→  109
→  109
→  109
→  110
→  110
