Endress+Hauser Proline Promass H 300 PROFINET Operating Instructions Manual page 247

Proline Promass H 300 PROFINET
Certification PROFINET
Pressure Equipment
Directive
Radio approval
Additional certification
Other standards and
guidelines
Endress+Hauser
PROFINET interface
The measuring device is certified and registered by the PNO (PROFIBUS User
Organization). The measuring system meets all the requirements of the following
specifications:
• Certified according to:
• Test specification for PROFINET devices
• PROFINET Security Level 2 – Netload Class
• The device can also be operated with certified devices of other manufacturers
(interoperability)
• The device supports PROFINET S2 system redundancy.
• With the identification PED/G1/x (x = category) on the sensor nameplate,
Endress+Hauser confirms conformity with the "Essential Safety Requirements" specified
in Appendix I of the Pressure Equipment Directive 2014/68/EU.
• Devices not bearing this marking (PED) are designed and manufactured according to
good engineering practice. They meet the requirements of Article 4 paragraph 3 of the
Pressure Equipment Directive 2014/68/EU. The range of application is indicated in
tables 6 to 9 in Annex II of the Pressure Equipment Directive 2014/68/EU.
The measuring device has radio approval.
For detailed information regarding radio approval, see Special Documentation
→  251
CRN approval
Some device versions have CRN approval. A CRN-approved process connection with a CSA
approval must be ordered for a CRN-approved device.
Tests and certificates
• EN10204-3.1 material certificate, parts and sensor housing in contact with medium
• Pressure testing, internal procedure, inspection certificate
• PMI test (XRF), internal procedure, wetted parts, test report
• EN10204-2.1 confirmation of compliance with the order and EN10204-2.2 test report
• EN 60529
Degrees of protection provided by enclosures (IP code)
• IEC/EN 60068-2-6
Environmental influences: Test procedure - Test Fc: vibrate (sinusoidal).
• IEC/EN 60068-2-31
Environmental influences: Test procedure - Test Ec: shocks due to rough handling,
primarily for devices.
• EN 61010-1
Safety requirements for electrical equipment for measurement, control and laboratory
use - general requirements
• IEC/EN 61326
Emission in accordance with Class A requirements. Electromagnetic compatibility (EMC
requirements).
• NAMUR NE 21
Electromagnetic compatibility (EMC) of industrial process and laboratory control
equipment
• NAMUR NE 32
Data retention in the event of a power failure in field and control instruments with
microprocessors
Technical data
247
