- Page 1 TQ6702e GEN2 OUTDOOR WIRELESS ACCESS POINT AT-TQ6702e GEN2 IEEE802.11ax Dual-radio 5GHz/2.4GHz 8x8+4x4 Wireless AP Installation Guide 613-003121 Rev. A...
- Page 2 Allied Telesis, Inc. has been advised of, known, or should have known, the...
- Page 3 Federal Communications Commission Interference Statement Declaration of Conformity Manufacturer Name: Allied Telesis, Inc. Declares that the product: Indoor and Outdoor Wireless Access Point Model Number: AT-TQ6702e GEN2 This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.
- Page 4 European Union Restriction of the Use of Certain Hazardous Substances (RoHS) in Electrical and Electronic Equipment This Allied Telesis RoHS-compliant product conforms to the European Union Restriction of the Use of Certain Hazardous Substances (RoHS) in Electrical and Electronic Equipment. Allied Telesis ensures RoHS conformance by requiring supplier Declarations of Conformity, monitoring incoming materials, and maintaining manufacturing process controls.
- Page 5 Wire Communications • IEEE 802.1 • IEEE 802.3 • IEEE 802.3u • IEEE 802.3x • IEEE 802.3ab • IEEE 802.3af • IEEE 802.3ah • IEEE 802.3bt Wireless Communications • IEEE 802.11 DSSS • IEEE 802.11a OFDM • IEEE 802.11b DSSS/FHSS •...
- Page 6 Electromagnetic Susceptibility - EN55024 • IEC 61000-3-2:2014 • IEC 61000-3-3:2013 • IEC 61000-4-2:2008 • IEC 61000-4-3:2006+A1:2007+A2:2010 • IEC 61000-4-4:2012 • IEC 61000-4-5:2017 • IEC 61000-4-6:2013 • (IEC 61000-4-8:2009) • IEC 61000-4-11:2014/AMD:2017 • IEC 61000-3-2:2014 • IEC 61000-3-3:2013 • 47 CFR Part 15, Subpart C •...
- Page 7 • AS/NZS CISPR 32: 2015 • AS/NZS 4268: 2017 China SRRC Hong Kong OFCA India WPC Indonesia SDPPI Israel MOC Japan • ARIB STD-T66 • ARIB STD-T71 Korea KC Malaysia SIRIM Mexico NOM Philippine NTC Singapore IMDA and TS SRD Complies with IMDA Standards DB102434...
- Page 8 Translated Safety Statements Important: Safety statements that have the symbol are translated into multiple languages in the Translated Safety Statements document at www.alliedtelesis.com/library. Remarque: Les consignes de sécurité portant le symbole sont traduites dans plusieurs langues dans le document Translated Safety Statements, disponible à l'adresse www.alliedtelesis.com/ library.
-
Page 9: Table Of Contents
Safety Symbols Used in this Document ..................... 16 Professional Installation Instructions......................17 Contacting Allied Telesis..........................18 Chapter 1: Product Description ........................19 Features of the TQ6702e GEN2 Access Point ..................20 TQ6000 GEN2 Models..........................22 Management Tools ............................ 23 Web Browser ............................23 Vista Manager EX and AWC Plug-in .................... - Page 10 Attaching the Cables to the TQ0301 Patch Antenna..................78 Installing the TQ0301 Antenna and TQ6702e GEN2 Access Point ............79 Attaching the Cable to the TQ6702e GEN2 Access Point ..............80 Appendix A: Technical Specifications and Statements ................83 TQ6702e GEN2 Access Point Specifications..................... 83 Physical Specifications.........................83...
- Page 11 Figure 42: Attaching the Cables to the Antenna Connectors....................78 Figure 43: TQ6702e GEN2 Access Point and TQ0301 Patch Antenna ................79 Figure 44: Cables and Antenna Connectors on the TQ6702e GEN2 Access Point .............80 Figure 45: Attaching the cable to an Antenna Connector .....................81...
- Page 12 TQ6702e GEN2 Outdoor Access Point Installation Guide...
- Page 13 Tables Table 1. Specifications of the TQ6702e GEN2 Wireless Access Points ................22 Table 2. Components of the Access Point ..........................25 Table 3. LEDs ..................................28 Table 4. Components in the TQ6702e Access Point Shipping Boxes ................36 Table 5. Pole Sizes and Angles ............................57 Table 6.
- Page 14 TQ6702e GEN2 Outdoor Access Point Installation Guide...
-
Page 15: Preface
Preface This guide contains the hardware installation instructions for the following products: TQ6702e GEN2 Outdoor Wireless Access Point TQ0301 Dual-band Patch Antenna TQ0064 RF Extension Cable This preface contains the following sections: “Safety Symbols Used in this Document” on page 16 ... -
Page 16: Safety Symbols Used In This Document
TQ6702e GEN2 Outdoor Access Point Installation Guide Safety Symbols Used in this Document This document uses the following conventions. Note Notes provide additional information. Caution Cautions inform you that performing or omitting a specific action may result in equipment damage or loss of data. -
Page 17: Professional Installation Instructions
Preface Professional Installation Instructions You must comply with the following cautions: Installation personnel This product is designed for specific applications and needs to be installed by a qualified individual who has RF and related rule knowledge. The general user shall not attempt to install the product or modify the settings. -
Page 18: Contacting Allied Telesis
TQ6702e GEN2 Outdoor Access Point Installation Guide Contacting Allied Telesis If you need assistance with this product, visit the Allied Telesis web site at www.alliedtelesis.com/support. -
Page 19: Chapter 1: Product Description
Chapter 1 Product Description This chapter describes the hardware components of the TQ6702e GEN2 access point and optional antenna and cables. This chapter contains the following sections: “Features of the TQ6702e GEN2 Access Point” on page 20 “TQ6000 GEN2 Models” on page 22 ... -
Page 20: Features Of The Tq6702E Gen2 Access Point
TQ6702e GEN2 Outdoor Access Point Installation Guide Features of the TQ6702e GEN2 Access Point The TQ6702e GEN2 Wireless Access Point is a dual-radio access point with 4x4 (2.4GHz) and 8x8 (5GHz) Wi-Fi 6 wireless connectivity. This access point is suitable for both indoor and outdoor environments. With the PoE++ LAN port, the access point can be connected to your wired network and powered from a PoE++ power source device. - Page 21 Chapter 1: Product Description Auto-Negotiation for speed and duplex mode Auto MDI-MDIX Basic software features include: Zero Wait DFS Flow control (IEEE 802.3x) VLAN tagging (IEEE 802.1Q) Link aggregation Cascade configuration On-board web browser management interface ...
-
Page 22: Tq6000 Gen2 Models
TQm6702 GEN2 TQ6602 GEN2 TQm6602 GEN2 TQ6702e GEN2 Table 1 lists their main differences. Table 1. Specifications of the TQ6702e GEN2 Wireless Access Points Indoor / Channel Max Number of Model Antenna Power Outdoor Port Blanket... -
Page 23: Management Tools
You can use SNMPv1 or SNMPv2 to view the parameter settings of the device. The MIB is available from the Allied Telesis web site. For instructions on how to configure the unit for SNMP, refer to Allied Telesis TQ6000 GEN2 Wireless Access Points Management Software User’s Guide. -
Page 24: Tq6702E Gen2 Access Point
Connectors Antenna Connector Antenna Connector LEDs and Ethernet LAN Reset Button and PoE++ Port Figure 1. Front Panel of the TQ6702e GEN2 Access Point The back panel components are illustrated in Figure 2. ® Gore Vent 5GHz Antenna Connectors 2.5 / 5GHz Dual-band Antenna Connectors Figure 2. -
Page 25: Lan Port
Do not remove the Gore® vent plug from the access point. LAN Port The TQ6702e GEN2 access point has one Ethernet LAN port on the front panel. The port has two functions. The first is to connect the wireless clients to your wired Local Area Network (LAN). The second is to receive power for the product from a PoE++ source device. -
Page 26: Power Over Ethernet (Poe++)
Ethernet LAN Port Figure 3. Ethernet LAN Port Power over The TQ6702e GEN2 access point supports Power over Ethernet Plus (PoE++) on the LAN port. As such, the access point receives its power Ethernet (PoE++) from a PoE++ source device over the network cable that also carries the network traffic. -
Page 27: Automatic Mdix Detection
Chapter 1: Product Description Note The LAN port should be connected to a network device that also sets its duplex mode with Auto-Negotiation. If the network device does not support Auto-Negotiation, the LAN port operates at half- duplex mode. This may result in a duplex mode mismatch if the network device is operating at full duplex. -
Page 28: Reset Button
TQ6702e GEN2 Outdoor Access Point Installation Guide The LEDs are described in Table 3. Table 3. LEDs State Description Solid Green The LAN port is receiving power from a PoE++ source device and is operating normally. Blinking The LAN port is receiving power from a PoE++... -
Page 29: Ethernet Cable Requirements
Chapter 1: Product Description You can use the reset button to return the parameter settings of the device to their default values. You might reset the access point if you want to discard its current configuration or because you forgot the password to the manager account and so cannot manage the device. -
Page 30: Tq0301 Patch Antenna And Tq0064 Rf Extension Cable
TQ6702e GEN2 Outdoor Access Point Installation Guide TQ0301 Patch Antenna and TQ0064 RF Extension Cable The TQ6702e GEN2 access point comes with four 2.4G/5GHz dual-band antennas and four 5GHz antennas. To extend coverage range, Allied Telesis offers the TQ0301 dual-band patch antenna with four 2 meter long cables. -
Page 31: Figure 7: Tq0301 Ports
Chapter 1: Product Description See Figure 7 for the port numbers on the TQ0301 patch antenna. Port 3 Port 1 Port 2 Port 4 Figure 7. TQ0301 Ports The TQ0064 10 meter RF cable is illustrated in Figure 8. Figure 8. TQ0064 10m RF Extension Cable... - Page 32 TQ6702e GEN2 Outdoor Access Point Installation Guide...
-
Page 33: Chapter 2: Installing The Access Point
Chapter 2 Installing the Access Point This chapter contains the following installation procedures for the TQ6702e GEN2 access point: “Reviewing Safety Precautions” on page 34 “Unpacking the Access Point” on page 36 “Attaching the Ground Cable to the Access Point” on page 39 ... -
Page 34: Reviewing Safety Precautions
TQ6702e GEN2 Outdoor Access Point Installation Guide Reviewing Safety Precautions Please review the following safety precautions before beginning the installation procedures. Note indicates that a translation of the safety statement is available in a PDF document titled Translated Safety Statements on the Allied Telesis website at www.alliedtelesis.com/support. - Page 35 Chapter 2: Installing the Access Point Note You should verify that your PoE network adheres to the standards of a separated extra-low voltage (SELV) circuit before using the PoE feature on the wireless access point. Warning Only trained and qualified personnel are allowed to install or to replace this equipment.
-
Page 36: Unpacking The Access Point
TQ6702e GEN2 Outdoor Access Point Installation Guide Unpacking the Access Point To unpack the access point, perform the following procedure: 1. Remove all components from the shipping boxes. Note Store the packaging material in a safe location. You must use the original shipping material if you need to return the unit to Allied Telesis. - Page 37 Chapter 2: Installing the Access Point Table 4. Components in the TQ6702e Access Point Shipping Boxes (Continued) Name Component One Mounting Base Four sets of a screw (M6xP1.0 16mm), washer, and spring washer for attaching the mounting base to the access point One pole-mount bracket Four sets of Hex-head bolts, washers, and spring Washers...
- Page 38 Eight external surge protectors with nuts and metal and rubber washers Ground Note The ground lug on the surge protector is not used. 3. If any item is missing or damaged, contact your Allied Telesis sales representative for assistance.
-
Page 39: Attaching The Ground Cable To The Access Point
What to Prepare You need the following items to attach the ground cable to the access point: for Attaching the Ground Cable TQ6702e GEN2 Access Point Ground cable One screw for the ground cable ... -
Page 40: Figure 9: Ground Posts
TQ6702e GEN2 Outdoor Access Point Installation Guide Ground Posts Figure 9. Ground Posts 3. Insert the screw through the ground lug on the ground wire and secure the wire to the selected ground post on the access point, using a Phillips-head screwdriver. - Page 41 Chapter 2: Installing the Access Point Note The ground wire should be 20AWG or larger and the screw should be 3.5mm or larger. 4. Attach the other end of the ground wire to a circuit breaker, ground rod, or earth ground. Note Keep the ground cable as short as possible;...
-
Page 42: Connecting An Ethernet Cable To The Access Point
TQ6702e GEN2 Outdoor Access Point Installation Guide Connecting an Ethernet Cable to the Access Point To connect an Ethernet cable to the access point, perform the following procedure: 1. Place the access point right-side up on a table or desk. -
Page 43: Figure 12: Sealing Nut, Clamping Claw, And Sealing Insert
Chapter 2: Installing the Access Point 3. Disassemble the sealing nut, clamping claw, and sealing insert. Refer to Figure 12. Sealing Insert Clamping Claw Sealing Nut Figure 12. Sealing Nut, Clamping Claw, and Sealing Insert 4. Slide the Ethernet LAN cable through the sealing nut and clamping claw. -
Page 44: Figure 14: Installing The Sealing Insert
TQ6702e GEN2 Outdoor Access Point Installation Guide Groove Figure 14. Installing the Sealing Insert 6. Slide the sealing insert into the clawing clamp. Refer to Figure 15. Figure 15. Inserting the Sealing Insert in the Clawing Clamp 7. Connect the RJ-45 connector on the Ethernet cable into the Ethernet... -
Page 45: Figure 16: Connecting The Lan Cable To The Ethernet Lan Port
Figure 17. Tightening the Sealing Nut Note The next step powers on the access point by attaching the Ethernet cable to a port on a PoE++ source device. Allied Telesis recommends not performing the step until you have completed all of the installation procedures. -
Page 46: Attaching The Antennas To The Access Point
TQ6702e GEN2 Outdoor Access Point Installation Guide Attaching the Antennas to the Access Point To install the antennas, perform the following procedure: Note You must install 5GHz antennas to 5GHz antenna connectors and 2.4GHz antennas to 2.4GHz antenna connectors. 1. Remove the blind caps covering the antenna connectors. -
Page 47: Figure 20: Installing The Metal And Rubber Washers On The Surge Protector
Chapter 2: Installing the Access Point 4. Install the metal and rubber washers, in that order, on the surge protector. Figure 20. Installing the Metal and Rubber Washers on the Surge Protector 5. Screw an antenna onto the surge protector. Refer to Figure 21. Figure 21. -
Page 48: Figure 22: Tightening The Nut To Secure The Antenna
TQ6702e GEN2 Outdoor Access Point Installation Guide 6. Tighten the nut against the antenna to secure the antenna. Refer to Figure 22. Figure 22. Tightening the Nut to Secure the Antenna 7. Repeat this procedure to install the remaining antennas. See Figure... -
Page 49: Installing The Access Point
Chapter 2: Installing the Access Point Installing the Access Point The access point can be installed on a desktop, ceiling, wall or pole. Guidelines to Review the following guidelines before installing the access point on a fixture: Installing the Access Point on a Attach the ground cable to the access point before attaching the ... -
Page 50: Figure 25: Correct Orientation
TQ6702e GEN2 Outdoor Access Point Installation Guide The access point can be installed on a pole or wall with the front panel facing down. See Figure 25. The front panel is the panel with the LAN port, as shown in Figure 1 on page 24. -
Page 51: Installation Instructions
Chapter 2: Installing the Access Point The access point must not be installed in the orientations shown in Figure 26. Figure 26. Invalid Orientations of the Access Point Installation The following sections contain the installation instructions. Review the “Guidelines to Installing the Access Point on a Fixture” on page 49 before Instructions installing the access point: “Installing the Access Point on a Wall”... -
Page 52: Installing The Access Point On A Wall
TQ6702e GEN2 Outdoor Access Point Installation Guide Installing the Access Point on a Wall This section contains the procedures for installing the TQ6702e GEN2 access point on a wall. What to Prepare You need the following items to install the access point on a wall:... -
Page 53: Figure 27: Marking The Mounting Base Holes On The Wall
Chapter 2: Installing the Access Point Figure 27. Marking the Mounting Base Holes on the Wall 3. Pre-drill the marked locations on the wall. 4. Install the provided wall anchors in the holes. 5. Place the access point upside-down on a table or desk. 6. -
Page 54: Figure 28: Attaching The Mounting Base To The Access Point
TQ6702e GEN2 Outdoor Access Point Installation Guide Correct Order of Washers Screw (M6xP1.0 16mm) Spring Washer Washer Figure 28. Attaching the Mounting Base to the Access Point 7. Attach the access point to the wall with the provided screws, using a... -
Page 55: Figure 29: Attaching The Access Point To The Wall
Chapter 2: Installing the Access Point Figure 29. Attaching the Access Point to the Wall... -
Page 56: Installing The Access Point On A Pole
TQ6702e GEN2 Outdoor Access Point Installation Guide Installing the Access Point on a Pole The TQ6702e GEN2 access point can be mounted on a pole using the U-bolts and pole-mount bracket or the pole straps and mounting bas. See Figure 30. -
Page 57: Table 5. Pole Sizes And Angles
Chapter 2: Installing the Access Point Table 5. Pole Sizes and Angles Angle Method Pole Diameter Range Adjustable U-bolts Φ35mm to 55mm with Pole-mount Bracket Pole Straps Φ80mm to 100mm with Mounting Base Another difference among two methods is whether the angle of the access point is adjustable. -
Page 58: Vertical Pole And Horizontal Pole
TQ6702e GEN2 Outdoor Access Point Installation Guide Vertical Pole and Your can install the access point on a pole that stands vertically or runs horizontally.See Figure 31. Horizontal Pole For the orientations of the access point, see Figure 26 on page 51. -
Page 59: Installing On A Pole Using The U-Bolts And Pole-Mount Bracket
What to Prepare You need the following items to install the access point on a pole using the U-bolts and pole mount bracket: for Pole Installation Using TQ6702e GEN2 access point the U-Bolts and Pole mount bracket Pole-Mount Four sets of screws, spring washers, and washers for the pole ... -
Page 60: Figure 32: Attaching The Pole-Mount Bracket To The Pole
TQ6702e GEN2 Outdoor Access Point Installation Guide Figure 32. Attaching the Pole-Mount Bracket to the Pole 3. Attach the access point to the pole-mount bracket with the screws using a Phillips-head screwdriver. See Figure 33 on page 61. Note Figure 32 shows how to attach the pole mount bracket to a vertical pole as an example. -
Page 61: Adjusting The Position Upwards Or Downwards
Chapter 2: Installing the Access Point Figure 33. Attaching the Access Point to the Pole-Mount Brackets Adjusting the To adjust the angle of the access point upwards or downwards, perform the following procedure: Position Upwards or Downwards 1. Loose the two bolts located on the sides of the pole mount brackets using an adjustable wrench or a 10mm socket and ratchet. -
Page 62: Installing On A Pole Using The Pole Straps And Mounting Base
TQ6702e GEN2 Outdoor Access Point Installation Guide Installing on a Pole Using the Pole Straps and Mounting Base To use the pole straps and mounting base to install the access point, the pole diameter must be from 80mm to 100mm. -
Page 63: Figure 34: Threading The Pole Straps
Chapter 2: Installing the Access Point 3. Thread one pole strap through the holes marked 1 to attach to the mounting base. Repeat to thread the other pole strap. See Figure 34. Figure 34. Threading the Pole Straps Note Figure 34 shows how to install the access point to a vertical pole. To install the access point on a horizontal pole, use the holes marked 2 to attach the pole straps to the mounting base. -
Page 64: Figure 35: Wrapping The Pole Straps Around The Pole
TQ6702e GEN2 Outdoor Access Point Installation Guide 4. Wrap the pole straps around the pole as shown in Figure 35. Figure 35. Wrapping the Pole Straps Around the Pole... -
Page 65: Figure 36: Inserting The Strap Ends Into The Screws
Chapter 2: Installing the Access Point 5. Insert the ends of the pole straps beneath the strap screws. Refer to Figure 36. Figure 36. Inserting the Strap Ends into the Screws... -
Page 66: Figure 37: Tightening The Straps
TQ6702e GEN2 Outdoor Access Point Installation Guide 6. Tighten the screws with a Phillips-head screwdriver to secure the access point to the pole. See Figure 37. Figure 37. Tightening the Straps... -
Page 67: Starting The First Management Session On The Access Point
Chapter 2: Installing the Access Point Starting the First Management Session on the Access Point The wireless access point firmware includes a DHCP client. The default setting for the client is enabled. When you power on the access point, it queries the subnet on the LAN port for a DHCP server. -
Page 68: Figure 38: Login Window
TQ6702e GEN2 Outdoor Access Point Installation Guide Figure 38. Login Window 4. Enter “manager” for the username and “friend” for the password. The username and password are case-sensitive. 5. Go to “Setting the Country and Location” on page 69. -
Page 69: Setting The Country And Location
Chapter 2: Installing the Access Point Setting the Country and Location You should set the country and location during the initial management session of the access point to ensure that the device operates in compliance with the codes and regulations of your region or country. Note The non-US model of this product has a country code setting that must be set during the initial management session of the unit. -
Page 70: Setting The Location
TQ6702e GEN2 Outdoor Access Point Installation Guide 2. Select the Country pull-down menu and select your country or region. Note If the Country pull-down menu is deactivated and cannot be changed, the country parameter was set when the unit was manufactured. -
Page 71: Rebooting The Access Point
Chapter 2: Installing the Access Point 2. Select the Location pull-down menu and select Indoor or Outdoor. Allied Telesis recommends rebooting the access point after changing the country and/or location setting. Rebooting the To reboot the unit, either power off on the unit or continue with these... - Page 72 TQ6702e GEN2 Outdoor Access Point Installation Guide...
-
Page 73: Chapter 3: Installing The Tq0301 Patch Antenna And Tq0064 Extension Cable
“Unpacking the TQ0064 Extension Cable” on page 76 “Installing the TQ0301 Patch Antenna on a Pole” on page 77 “Attaching the Cables to the TQ0301 Patch Antenna” on page 78 “Installing the TQ0301 Antenna and TQ6702e GEN2 Access Point” on page 79... -
Page 74: Unpacking The Tq0301 Dual-Band Patch Antenna
TQ6702e GEN2 Outdoor Access Point Installation Guide Unpacking the TQ0301 Dual-band Patch Antenna To unpack the TQ0301 patch antenna, perform the following procedure: 1. Remove all components from the shipping boxes. Note Store the packaging material in a safe location. You must use the original shipping material if you need to return the unit to Allied Telesis. - Page 75 Component Four SMA to N jack conversion adapters Note The adapters are not used for the TQ6702e GEN2 access point. Two metal protective caps 3. If any item is missing or damaged, contact your Allied Telesis sales representative for assistance.
-
Page 76: Unpacking The Tq0064 Extension Cable
2. Verify that the component listed in Table 7 is included in your shipping boxes. Table 7. Component in the TQ0064 Extension Cable Shipping Boxes Name Component 10 meter Cable 3. If any item is missing or damaged, contact your Allied Telesis sales representative for assistance. -
Page 77: Installing The Tq0301 Patch Antenna On A Pole
Chapter 3: Installing the TQ0301 Patch Antenna and TQ0064 Extension Cable Installing the TQ0301 Patch Antenna on a Pole The TQ0301 patch antenna can be mounted on a pole with the pole-mount brackets. See Figure 41. Pole-mount brackets Figure 41. TQ0301 Patch Antenna on a Polr Guideline for Review the following guideline before installing the access point on a pole: Pole Installation... -
Page 78: Attaching The Cables To The Tq0301 Patch Antenna
TQ6702e GEN2 Outdoor Access Point Installation Guide Attaching the Cables to the TQ0301 Patch Antenna Allied Telesis offers two types of cables for the TQ0301 patch antenna: Two meter cable: comes with the TQ0301 TQ0064 Ten meter cable ... -
Page 79: Installing The Tq0301 Antenna And Tq6702E Gen2 Access Point
The TQ6702e GEN2 access point has two types of antenna connectors: 5GHz antenna connectors 2.4G/5GHz dual-band antenna connectors Note For details, see Figure 1 on page 24 and Figure 2 on page 24. Figure 44 on page 80 shows cable connections to the TQ6702e GEN2 access point. -
Page 80: Attaching The Cable To The Tq6702E Gen2 Access Point
5, 6, 7, and 8 1, 2, 3, and 4 Figure 44. Cables and Antenna Connectors on the TQ6702e GEN2 Access Point Attaching the To attach the cables to the TQ6702e GEN2 access point, perform the following procedure: Cable to the TQ6702e GEN2 Note... -
Page 81: Figure 45: Attaching The Cable To An Antenna Connector
Chapter 3: Installing the TQ0301 Patch Antenna and TQ0064 Extension Cable Figure 45. Attaching the cable to an Antenna Connector... - Page 82 TQ6702e GEN2 Outdoor Access Point Installation Guide...
-
Page 83: Appendix A: Technical Specifications And Statements
This appendix contains the following sections: “TQ6702e GEN2 Access Point Specifications” “TQ0301Patch Antenna Specifications” on page 84 “TQ0064 and Cables in TQ6702e GEN2 Access Point Specifications” on page 85 “LAN Port” on page 87 “Operation Frequency Information” on page 89 ... -
Page 84: Physical Specifications
TQ6702e GEN2 Outdoor Access Point Installation Guide Power Table 10. TQ6702e GEN2 Maximum Power Consumption Specifications TQ6702e GEN2 29.2 watts Antenna This radio transmitter has been approved by Innovation, Science and Economic Development Canada to operate with the antenna types listed Specifications below, with the maximum permissible gain indicated. -
Page 85: Product Specifications
50 ohms Feed Impedance Power Table 16. TQ0301 Power Input Specifications Maximum input power 50 watts TQ0064 and Cables in TQ6702e GEN2 Access Point Specifications Physical Table 17. Cable Physical Specifiations Specifications TQ0064 Cable in TQ6702e GEN2 Length 10 meter... -
Page 86: Environmental Specifications
TQ6702e GEN2 Outdoor Access Point Installation Guide Environmental Table 18. Cable Environmental Specifications Specifications Operating Temperature -40° C to 80° C (-40° F to 176° F) Operating Humidity 5% to 95% non-condensing Product Table 19. Cable Product Specifications Specifications TQ0064... -
Page 87: Lan Port
Appendix A: Technical Specifications and Statements LAN Port Table 21 shows LAN port specifications. Table 21. LAN Port Specifications Connector RJ45 Standards IEEE 802.3 (10Base-T) IEEE 802.3u (100Base-TX) IEEE 802.3ab (1000Base-T) IEEE 802.3bz (2.5GBase-T, 5GBase-T) PoE standard IEEE 802.3bt (Class 5) Figure 46 illustrates the pin layout of the LAN port. -
Page 88: Table 24. 1000Base-T Connector Pinouts
TQ6702e GEN2 Outdoor Access Point Installation Guide Table 23. MDI-X Pin Signals (100Base-TX) (Continued) Signal Table 24 lists the pin signals when the LAN port is operating at 1000 Mbps. Table 24. 1000Base-T Connector Pinouts Pair Signal TX and RX... -
Page 89: Operation Frequency Information
Appendix A: Technical Specifications and Statements Operation Frequency Information Table 25. Operation Frequency 2.4GHz 5150~5250GHz 5250~5350GHz 5470~5725GHz 5725~5850GHz Indoor Outdoor Indoor Outdoor Indoor Outdoor Indoor Outdoor Indoor Outdoor √ √ √ √ √ √ √ √ √ √ √ √ √... -
Page 90: Ic Statements
TQ6702e GEN2 Outdoor Access Point Installation Guide IC Statements This device contains license-exempt transmitter(s)/receiver(s) that comply with Innovation, Science and Economic Development Canada’s license- exempt RSS(s). Operation is subject to the following two conditions: (1) This device may not cause interference. -
Page 91: Avertissement
Appendix A: Technical Specifications and Statements (iv) Users should also be advised that high-power radars are allocated as primary users (i.e. priority users) of the bands 5250-5350 MHz and 5650- 5850 MHz and that these radars could cause interference and/or damage to LE-LAN devices. -
Page 92: Europe - Eu Declaration Of Conformity
20 cm between the radiator and your Statement body. Importer Allied Telesis International BV Incheonweg 7, 1437 EK Rozenburg Note Contact Allied Telesis for the EU conformity statement. To contact AlliedTelesis, visit our web site at www.alliedtelesis.com/contact. -
Page 93: Uk - Ukca Declaration Of Conformity
Appendix A: Technical Specifications and Statements UK - UKCA Declaration of Conformity Hereby, Allied Telesis declares that the radio equipment type [AT-TQ6702e GEN2] is in compliance with The Radio Equipment Regulations 2017. Operating The operating frequencies and maximum transmission power levels for... - Page 94 TQ6702e GEN2 Outdoor Access Point Installation Guide...
