Chapter 2: Jumpers and Connectors
I/O Board CPLD JTAG Header
Connector size: 1 x 6 = 6 Pin , 2.54mm
Connector location: JP12
1
6
Pin
Definition
1
P3V3_AUX
2
GND
3
JTAG_CPLD_TCK
4
JTAG_CPLD_TDO
5
JTAG_CPLD_TDI
6
JTAG_CPLD_TMS
This header is designed to update CPLD firmware with a
diamond programmer.
Copyright © 2023 NEXCOM International Co., Ltd. All Rights Reserved.
47
FTA 1170 Series User Manual
