Chapter 2: Jumpers and Connectors
Pin
Definition
61
GND
62
GND
63
3258_L0_TX_P
64
3258_L2_RX_P_C
65
3258_L0_TX_N
66
3258_L2_RX_N_C
67
GND
68
GND
69
3258_L1_TX_P
70
3258_L3_RX_P_C
71
3258_L1_TX_N
72
3258_L3_RX_N_C
73
GND
74
GND
75
3258_L2_TX_P
Copyright © 2023 NEXCOM International Co., Ltd. All Rights Reserved.
Pin
Definition
76
5G_LTE_TX_DP0_C
77
3258_L2_TX_N
78
5G_LTE_TX_DN0_C
79
GND
80
GND
81
3258_L3_TX_P
82
5G_LTE_TX_DP1_C
83
3258_L3_TX_N
84
5G_LTE_TX_DN1_C
85
GND
86
GND
87
CLK_OUT_DP6
88
5G_LTE_TX_DP2_C
89
CLK_OUT_DN6
90
5G_LTE_TX_DN2_C
Pin
Definition
91
GND
92
GND
93
CLK_OUT_DP7
94
USB3_TX_P1_C
95
CLK_OUT_DN7
96
USB3_TX_N1_C
97
GND
98
GND
99
SMB_GBE0_I2C_CLK_R
100
5G_LTE_RX_DP0_C
101
SMB_GBE0_I2C_DATA_R
102
5G_LTE_RX_DN0_C
103
GND
104
GND
105
SMB_GBE1_I2C_CLK_R
29
Pin
Definition
106
5G_LTE_RX_DP1
107
SMB_GBE1_I2C_DATA_R
108
5G_LTE_RX_DN1
109
GND
110
GND
111
SMB_GBE2_I2C_CLK_R
112
5G_LTE_RX_DP2
113
SMB_GBE2_I2C_DATA_R
114
5G_LTE_RX_DN2
115
GND
116
GND
117
SMB_GBE3_I2C_CLK_R
118
USB3_RX_P1_C
119
SMB_GBE3_I2C_DATA_R
120
USB3_RX_N1_C
FTA 1170 Series User Manual
