Chapter 2: Jumpers and Connectors
Pin Definition
121 GND
122 GND
123 BYPASS_SLOT_B
124 P3V3_AUX
125 BYPASS_SLOT_C
126 P3V3_AUX
127 GND
128 GND
129 BYPASS_SLOT_D
130 P12V_S2
131 N.C.
132 P12V_S2
133 N.C.
134 GND
135 N.C.
Copyright © 2023 NEXCOM International Co., Ltd. All Rights Reserved.
Pin Definition
136 P12V_S2
137 N.C.
138 P12V_S2
139 N.C.
140 GND
141 N.C.
142 P12V_S2
143 N.C.
144 P12V_S2
145 N.C.
146 GND
147 N.C.
148 N.C.
149 N.C.
150 N.C.
