Chapter 2: Jumpers and Connectors
Pin Definition
197 GND
198 SPI1CS0#_GPIO116
199 I2C11SCL_GPIO117
200 SPI_IBMC_SSB_DO
201 I2C11SDA_GPIO118
202 SPI_SSB_IBMC_DI
203 GND
204 N.C.
205 I2C3SCL_GPIO119
206 N.C.
207 I2C3SDA_GPIO121
208 SPI_IBMC_SSB_CLK
209 N.C.
210 SPI1CS1#_GPIO124
211 N.C.
212 GND
Copyright © 2023 NEXCOM International Co., Ltd. All Rights Reserved.
Pin Definition
213 N.C.
214 N.C.
215 GND
216 RMIICRSDV
217 USB2_P3_DN
218 N.C.
219 USB2_P3_DP
220 NIC0_NCSI_CLK_IN_R
221 GND
222 GND
223 N.C.
224 RMIITXEN
225 N.C.
226 GND
227 GND
228 RMIIRXD0
Pin Definition
229 N.C.
230 RMIIRXD1
231 N.C.
232 GND
233 GND
234 PU_NIC0_NCSI_TXD_0
235 N.C.
236 PU_NIC0_NCSI_TXD_1
237 N.C.
238 GND
239 GND
240 N.C.
241 N.C.
242 N.C.
243 N.C.
244 N.C.
23
Pin Definition
245 GND
246 N.C.
247 N.C.
248 N.C.
249 N.C.
250 N.C.
251 GND
252 PVNN_PCH_ADC8
253 BMC_RESET#
254 P1V2_VDDQ_ADC9
255 P3V_RTC_ADC13
256 P5V_ADC10
257 P1V05_NAC_ADC11
258 P1V8_A_ADC12
259 N.C.
260 N.C.
