Chapter 2: Jumpers and Connectors
JP6 (for Marvell 2.5GBE RJ45 P17~P24 PoE)
Pin Definition
1 N.C.
2 VPORT_NEG_OUT20
3 N.C.
4 N.C.
5 N.C.
6 VPORT_NEG_OUT19
7 N.C.
8 N.C.
9 N.C.
10 VPORT_NEG_OUT18
Copyright © 2023 NEXCOM International Co., Ltd. All Rights Reserved.
Pin Definition
11 N.C.
12 N.C.
13 P12V
14 VPORT_NEG_OUT17
15 GND
16 V_52V_OUT
17 P3V3
18 V_52V_OUT
19 P3V3
20 V_52V_OUT
Pin Definition
21 GND
22 V_52V_OUT
23 POE3_DETECT
24 V_52V_OUT
25 GND
26 V_52V_OUT
27 DRG_SPI_MISO
28 VPORT_NEG_OUT24
29 GND
30 N.C.
45
Pin Definition
31 DRG_SPI_MOSI
32 VPORT_NEG_OUT23
33 GND
34 N.C.
35 DRG_SPI_SCK
36 VPORT_NEG_OUT22
37 GND
38 N.C.
39 DRG_SPI_CS
40 VPORT_NEG_OUT21
