Chapter 2: Jumpers and Connectors
Pin
Definition
61
GND
62
GND
63
PE_SOC_RX_DP9
64
PE_SOC_TX_C_DP9
65
PE_SOC_RX_DN9
66
PE_SOC_TX_C_DN9
67
GND
68
GND
69
PE_SOC_RX_DP10
70
PE_SOC_TX_C_DP10
71
PE_SOC_RX_DN10
72
PE_SOC_TX_C_DN10
73
GND
74
GND
75
PE_SOC_RX_DP11
Copyright © 2023 NEXCOM International Co., Ltd. All Rights Reserved.
Pin
Definition
76
PE_SOC_TX_C_DP11
77
PE_SOC_RX_DN11
78
PE_SOC_TX_C_DN11
79
GND
80
GND
81
PE_SOC_RX_DP12
82
PE_SOC_TX_C_DP12
83
PE_SOC_RX_DN12
84
PE_SOC_TX_C_DN12
85
GND
86
GND
87
PE_SOC_RX_DP13
88
PE_SOC_TX_C_DP13
89
PE_SOC_RX_DN13
90
PE_SOC_TX_C_DN13
Pin
Definition
91
GND
92
GND
93
PE_SOC_RX_DP14
94
PE_SOC_TX_C_DP14
95
PE_SOC_RX_DN14
96
PE_SOC_TX_C_DN14
97
GND
98
GND
99
PE_SOC_RX_DP15
100
PE_SOC_TX_C_DP15
101
PE_SOC_RX_DN15
102
PE_SOC_TX_C_DN15
103
GND
104
GND
105
CLK_PCIE_SLOT_P
26
Pin
Definition
106
DISCONN_A0_EN
107
CLK_PCIE_SLOT_N
108
DISCONN_A1_EN
109
GND
110
GND
111
DISCONN_A2_EN
112
P3V3_S
113
DISCONN_A3_EN
114
P3V3_S
115
GND
116
GND
117
BYPASS_SLOT_EN
118
P3V3_S
119
BYPASS_SLOT_A
120
P3V3_S
