Chapter 2: Jumpers and Connectors

CPLD JTAG Header

Connector size: 1 x 6 = 6 pin, 2.54mm
Connector location: JP26
1 6
Pin Definition
1 P3V3_AUX
2 GND
3 JTAG_PLD_TCK
4 JTAG_PLD_TDO
5 JTAG_PLD_TDI
6 JTAG_PLD_TMS
Copyright © 2023 NEXCOM International Co., Ltd. All Rights Reserved.

LPC TPM Module Header

Connector size: 2 x 7 = 14 pin, 2.0mm
Connector location: JP34
13 1
14 2
Pin Definition
1 GND
3 -
5 ESPI_IO3_LPC_AD2
7 ESPI_IO3_LPC_AD1
9 GND
11 INT_SERIRQ
13 GND
32
Pin Definition
2 CLK_LPC_TPM
4 H_LPC_FRAME_N
6 RST_TPM_N
8 ESPI_IO3_LPC_AD3
10 ESPI_IO3_LPC_AD0
12 P3V3_SOC
14 GND
