Chapter 2: Jumpers and Connectors
Pin Definition
41 SMB_NIC0_CLK
42 GND
43 SMB_NIC0_DAT
44 CLK_100M_NIC0_DN_R
45 LED_GBE0_LED2
46 CLK_100M_NIC0_DP_R
47 LED_GBE1_LED0
48 GND
49 LED_GBE1_LED1
50 P1E_NIC0_RX_DN
Copyright © 2023 NEXCOM International Co., Ltd. All Rights Reserved.
Pin Definition
51 LED_GBE1_LED2
52 P1E_NIC0_RX_DP
53 LED_GBE2_LED0
54 GND
55
LED_GBE2_LED1
56 P1E_NIC0_TX_C_DN
57 LED_GBE2_LED2
58 P1E_NIC0_TX_C_DP
59 LED_GBE3_LED0
60 GND
Pin Definition
61 LED_GBE3_LED1
62 GND
63 LED_GBE3_LED2
64 P3V3_AUX
65 POE_LED
66 P3V3_AUX
67 WIFI_LED
68 GND
69 HDD_CPLD_LED
70 P3V3_MB
38
Pin Definition
71 POWER_LED
72 P3V3_MB
73 GND
74 GND
75
P12V
76 P3V3_MB
77 P12V
78 P3V3_MB
79 GND
80 GND
