Chapter 2: Jumpers and Connectors
Pin Definition
121 GND
122 GND
123 SMB_CPLD_I2C_CLK_R
124 PEX_SW_RX_P
125 SMB_CPLD_I2C_DATA_R
126 PEX_SW_RX_N
127 GND
128 GND
129
RST_GBE_GPIO6_RST_0_N_R
130 PEX_SW_TX_P_C
131
FM_GBE_GPIO7_INT_0_N_R
132 PEX_SW_TX_N_C
133 GND
134 GND
135
FM_GBE_GPIO4_INT_1_N_R
Copyright © 2023 NEXCOM International Co., Ltd. All Rights Reserved.
Pin Definition
136
SMB_ETH_MNG_I2C_CLK_R
137 PD_GBE_GPIO5_R
138
SMB_ETH_MNG_I2C_DATA_R
139 GND
140 GND
141
FM_GBE_GPIO2_PRSNT_3_ N_R
142 RST_SW_LTB_RSTBTN_N
143
RST_GBE_GPIO3_RST_1_N_R
144 FM_SW_LTB_PWRBTN_N
145 GND
146 GND
147
RST_GBE_GPIO0_RST_3_N_R
148 CLK_100M_SW_DP
149
FM_GBE_GPIO1_INT_3_N_R
150 CLK_100M_SW_DN
