Chapter 2: Jumpers and Connectors
CPLD GPIO Header
Connector type: 2 x 5 = 10 pin, 2.0mm (4 GPI; 4 GPO)
Connector location: CN6
1
9
2
10
Pin
Definition
1
P3V3_AUX
3
CPLD_GPIN1
5
CPLD_GPIN2
7
CPLD_GPIN3
9
CPLD_GPIN4
Copyright © 2023 NEXCOM International Co., Ltd. All Rights Reserved.
Pin
Definition
2
GND
4
CPLD_GPOUT1
6
CPLD_GPOUT2
8
CPLD_GPOUT3
10
CPLD_GPOUT4
13
FTA 1170 Series User Manual
