Example Of Pa025Ct And Pa014Ir Connection; Example Of Pa025Ct And Pa014Ir Monitored Connection - Key Automation LEV3301L Instructions And Warnings For Installation And Use

EN

9.5 - Example of PA025CT and PA014IR connection

INTERNAL RADAR
EXTERNAL RADAR
9.6 - Example of monitored PA025CT and PA014IR connection
INTERNAL RADAR
EXTERNAL RADAR
60
RED AC/DC from 12 to 24 V
BLACK
AC/DC from 12 to 24 V
WHITE
N.O.
GREEN COM
YELLOW (+) MANIFOLD
BLUE (-)
TRANSMITTER
GREY (+)
TEST-P
TEST-N
BROWN (-)
RED
AC/DC from 12 to 24 V
BLACK
AC/DC from 12 to 24 V
WHITE
N.O.
GREEN
COM
YELLOW (+)
MANIFOLD
BLUE (-)
TRANSMITTER
GREY (+)
TEST-P
BROWN (-) TEST-N
RED AC/DC from 12 to 24 V
BLACK
AC/DC from 12 to 24 V
WHITE N.O.
COM
GREEN
YELLOW (+)
MANIFOLD
BLUE (-)
TRANSMITTER
GREY (+) TEST-P
TEST-N
BROWN (-)
RED
AC/DC from 12 to 24 V
BLACK
AC/DC from 12 to 24 V
WHITE
N.O.
GREEN
COM
YELLOW (+)
MANIFOLD
BLUE (-)
TRANSMITTER
GREY (+)
TEST-P
BROWN (-)
TEST-N
POWER
OUTPUT
R2,3,4,5
OUTPUT
R1,2
INPUT
TEST
POWER
OUTPUT
R2,3,4,5
OUTPUT
R1,2
INPUT
TEST
+24V
-24V
INT RAD
COM
EXT RAD MANI-
FOLD
+24V
TEST 2
+24V
-24V
EXT RAD
COM
TRANSMIT
INT RAD
COM
+24V
TEST 1
