Firmware Updates

If the need arises, you can replace the NBP firmware. This section covers the following
firmware-related topics:
•
•

Determining the Firmware Version

To check which firmware version the button panel is using, do one of the following:
•
•
Before using those methods, connect the NBP and the PC to the same network. For
details see the
starting on page 7 and the
starting on page 44.

Using Toolbelt Software

1.
2.
3.

Using a Browser

The NBP comes with a factory default embedded web page, where you can check the
firmware version as follows:
1.
2.
3.
Determining the Firmware Version
Updating the Firmware
View the device information in Toolbelt.
View the general status information section of the NBP embedded web page.
Hardware Features and Installation — Wall-mountable Models
Software-based Configuration and Control
Open the Toolbelt software.
Either add the desired control processor manually or start device discovery and select
the desired processor from the list of discovered devices.
Click on the IP address link or on the Manage icon (gear) in the row for the desired
control processor, select the applicable device management tabs, and view the device
information.
Start a browser program.
Type the IP address of the NBP into the address field of the browser and log on to the
internal web page.
Look for the version within one of the information panes.
Network Button Panels • Firmware Updates
section
section
53
