Mud Ring
Figure 22. Installing the NBP
in a Mud Ring
Network Button Panels • Hardware Features and Installation — Wall-mountable Models
For US gang models: Insert the included screws through the mounting holes at
the top and bottom of the unit, through the plastic spacer (if not using a mud ring),
and into the corresponding threaded holes in the box or mud ring (see figure 21 and
figure 22).
Junction
Box
Wall
e
P C
O P
P T
F
O F L A
O N
E O
V I D
T E
M U
NBP 100
Faceplate
b. Using a Phillips screwdriver, lightly tighten the mounting screws until snug.
ATTENTION:
Do not overtighten the screws.
•
Veillez à ne pas trop serrer les vis.
•
Wall
Plastic Spacer
NBP 100
Figure 21. Installing the NBP
in a Junction Box
n
t r o
NOTE: Extron recommends taking
E x
precautions to avoid electrostatic
discharge issues during
installation.
NOTE: If the unit is not installed
in a mud ring, you must install
the plastic spacer. The spacer
positions the unit to allow the
magnetic faceplate to attach
properly and securely.
e
P C
O P
P T
F
O F L A
O N
E O
V I D
T E
M U
E x
Faceplate
n
t r o
20
