IMPORTANT NOTES:
The factory configured password for this device has been set to the device serial
•
number. Passwords are case sensitive. Performing a Reset to Factory Defaults (see
Resetting the Unit
DHCP is off by default.
•
ATTENTION:
Power over Ethernet (PoE) is intended for indoor use only. It is to be connected
•
only to networks or circuits that are not routed to the outside plant or building.
L'alimentation via Ethernet (PoE) est destinée à une utilisation en intérieur
•
uniquement. Elle doit être connectée seulement à des réseaux ou des circuits qui
ne sont pas routés au réseau ou au bâtiment extérieur.
If not provided with a power supply, this product is intended to be supplied by
•
a UL Listed power source marked "Class 2" or "LPS" and rated output 48 VDC
(PoE), minimum 0.35 A, or 56 VDC (PoE), minimum 0.8 A.
Si le produit n'est pas fourni avec une source d'alimentation, il doit être alimenté
•
par une source d'alimentation certifiée UL de classe 2 ou LPS, avec une tension
nominale 48 Vcc (PoE), 0,35 A minimum, ou 56 VDC (PoE), 0,8 A minimum.
The installation must always be in accordance with the applicable provisions of
•
National Electrical Code ANSI/NFPA 70, article 725 and the Canadian Electrical
Code part 1, section 16. The power supply shall not be permanently fixed to
building structure or similar structure.
Cette installation doit toujours être conforme aux dispositions applicables du Code
•
américain de l'électricité (National Electrical Code) ANSI/NFPA 70, article 725, et
du Code canadien de l'électricité, partie 1, section 16. La source d'alimentation ne
devra pas être fixée de façon permanente à une structure de bâtiment ou à une
structure similaire.
The Network Button Panels are intended to be used with Extron Electronics
•
UL Listed products only.
L'utilisation des claviers de commande réseau est prévue uniquement avec des
•
produits certifiés UL Extron Electronics.
Cabling:
•
For 10Base-T (10 Mbps) networks, use a CAT 3 or better cable.
•
For 100Base-T (max. 155 Mbps) networks, use a CAT 5 cable.
Activity LED (on connector) — This yellow LED blinks to indicate network activity.
Link LED (on connector) — This green LED lights to indicate a good network connection.
MAC address — This is the unique user hardware ID number
(Media Access Control [MAC] address) of the unit (for example,
00-05-A6-05-1C-A0). You may need this address during
configuration. The label is on the back panel for decorator-style
models (see
figure 16
on page 16) and on the front panel for the
NBP 100 and NBP 200 (see
Network Button Panels • Hardware Features and Installation — Wall-mountable Models
on page 42) sets the password to extron.
figure 39
on page 38).
00-05-A6-XX-XX-XX
MAC: 00-05-A6-XX-XX-XX
S/N: ####### E######
MAC
Address
MAC: 00-05-A6-XX-XX-XX
S/N: ####### E######
17
