3.
Attach the wallplate to the NBP
For decorator-style models: Insert the included screws through the circular
•
holes in the wallplate and the tabs on the NBP (see
page 19). Hand tighten the screws using a flat bladed screwdriver until snug.
For US gang models: Align the faceplate openings with the buttons, knob, and
•
LEDs, and place the faceplate against the unit (see
previous page). The magnetic catches fasten the faceplate onto the front of the unit.
Network Button Panels • Hardware Features and Installation — Wall-mountable Models
figure 19
figure 20
and
on
figure 21
and
figure 22
on the
21
