ON
OFF
Figure 3.

Cable Cubby Model

The NBP 1200C features soft backlit buttons. It is mounted in a Cable Cubby enclosure so
it can be integrated into a table, desk, or lectern.
Figure 4.

Features

General features
• Configurable buttons — The system configuration sets button illumination (levels and
whether each button is lit steadily or blinking) and functions (commands, macros, and
so forth).
• A variety of mounting options — The NBP can be mounted in furniture or a wall, in
a lectern, table, or in a surface mount box, depending on the model.
• Power over Ethernet (PoE) — The NBPs support power over Ethernet, providing the
unit with both power and an Ethernet signal over a single connector.
PC LAPTOP
MEDIA
VIDEO
PLAYER
HDMI 1
HDMI 2
MUTE WIRELESS
Extro Extron
NBP 200 Front (Left) and Rear (Right) Views
NBP 1200C Front (Left) and Bottom (Right)
NBP 1200C NBP 1200C
RESET
R
00-05-A6-XX-XX-XX
MAC: 00-05-A6-XX-XX-XX
S/N: XXXXXXX EXXXXXX
LAN/PoE
LAN/PoE
Network Button Panels • Introduction 3
