Chapter 1

Compaq ProSignia 200 Features

Industry Support . .................................................................................................... 1-1

Comprehensive Customer Support .......................................................................... 1-2

Standard Features................................................................................................... 1-2

Front Panel Components . ................................................................................. 1-2

Removing the Side Access Panel . .................................................................... 1-3

Replacing the Side Access Panel . ..................................................................... 1-4

Removing the Front Bezel............................................................................... 1-5

Rear Panel Connectors ..................................................................................... 1-6

Drive Positions................................................................................................ 1-8

Processor Board............................................................................................... 1-9

Cache Memory...............................................................................................1-10

System Memory ..............................................................................................1-10

Expansion Slots..............................................................................................1-10

IDE Enhanced Disk Controller.......................................................................1-10

Network Controller.........................................................................................1-11

Video..............................................................................................................1-11

ROM..............................................................................................................1-11

Power Supply ..................................................................................................1-11

Warranty........................................................................................................1-11

Server Management and Configuration.................................................................1-12

Compaq SmartStart........................................................................................1-12

Compaq Insight Manager...............................................................................1-12

Automatic Server Recovery-2 (ASR-2) . ..........................................................1-13

Security Features...................................................................................................1-13

Getting Additional Configuration Information . ......................................................1-14

Writer: Compaq Computer Corporation Project: Contents Comments:

File Name: Toc.doc Last Saved On: 4/14/97 1:55 PM

Compaq ProSignia 200 Server Reference Guide

iii

Table of Contents

Need help?

Do you have a question about the ProSignia 200 and is the answer not in the manual?

Questions and answers

Summary of Contents for Compaq ProSignia 200

Page 1: Table Of Contents
Compaq SmartStart..................1-12 Compaq Insight Manager................1-12 Automatic Server Recovery-2 (ASR-2) ............1-13 Security Features....................1-13 Getting Additional Configuration Information ............1-14 Compaq ProSignia 200 Server Reference Guide Writer: Compaq Computer Corporation Project: Contents Comments: File Name: Toc.doc Last Saved On: 4/14/97 1:55 PM...
Page 2 Removing an Expansion Slot Cover ..............3-6 Installing an Expansion Board ................. 3-7 Replacing the Expansion Backplane Brace ............3-8 Installing a Processor Upgrade in Your ProSignia 200 Server ........3-10 Removing the System Board Tray ..............3-10 Removing the Processor ..................3-12 Installing the Processor ...................3-13...
Page 3 Loading Compaq Device Drivers ................4-11 NetWare Device Drivers from Compaq ............4-11 Windows NT Device Drivers from Compaq ............4-13 SCO OpenServer and SCO UnixWare Device Drivers from Compaq .....4-14 SCO OpenServer....................4-15 UnixWare.......................4-15 IBM OS/2 Device Drivers from Compaq ............4-16...
Page 4 ......Banyan VINES Device Drivers from Compaq ..........4-16 Diagnostics and Other Utilities ................4-17...
Page 5 7000 Series - Server Manager/R Board Test Error Codes ........8-30 8600 Series - Pointing Device Interface Test Error Codes .......8-31 Test Computer.......................8-31 Compaq ProSignia 200 Server Reference Guide Writer: Compaq Computer Corporation Project: Contents Comments: File Name: Toc.doc Last Saved On: 4/14/97 1:55 PM...
Page 6 Switches and Jumpers Setting System Board Switches and Jumpers ............D-1 Switch Settings SW1....................D-1 Jumper Settings......................D-2 Power-on Password E6...................D-2 Configuration Memory Invalidate E8 ..............D-2 Writer: Compaq Computer Corporation Project: Contents Comments: File Name: Toc.doc Last Saved On: 4/14/97 1:55 PM...
Page 7 Avis Canadien......................F-2 European Union (EU) Notice .................. F-3 Japanese Notice...................... F-3 Laser Safety......................F-3 Battery Notices....................... F-5 Index Compaq ProSignia 200 Server Reference Guide Writer: Compaq Computer Corporation Project: Contents Comments: File Name: Toc.doc Last Saved On: 4/14/97 1:55 PM...
Page 8 Using This Reference Guide This reference guide contains detailed information about the Compaq ProSignia 200 server. Following is a summary of each chapter: Chapter 1 − − Compaq ProSignia 200 Features This chapter provides a brief summary of the standard features of the ProSignia 200 server.
Page 9 Appendix B − − Power Cord Set Requirements This appendix contains requirements for the power cord set now available with the ProSignia 200 servers. A table lists power cord set requirements for each country. Appendix C − − Electrostatic Discharge This section suggests ways to prevent electrostatic discharge (ESD) and the damage it can cause.
Page 10 Enter key. Enter When you are instructed to enter information, type the information and then press the Enter key. Compaq ProSignia 200 Server Reference Guide Writer: Compaq Computer Corporation Project: Introduction Comments: File Name: B-intro.doc Last Saved On: 4/14/97 1:34 PM...
Page 11 The enclosed area contains no operator serviceable parts. To avoid risk of injury from electrical shock hazards, do not open this enclosure. Writer: Compaq Computer Corporation Project: Introduction Comments: File Name: B-intro.doc Last Saved On: 4/14/97 1:34 PM...
Page 12 In the United States, call 1-800-345-1518. In Canada, call 1-800-263-5868. For Compaq technical support in the United States and Canada, call 1-800-OKCOMPAQ (1-800-652-6672). Elsewhere, call one of the numbers listed in the following table to locate your nearest Authorized Compaq Reseller or Service Provider.
Page 13 #1 / 838 22 22 United Kingdom 081 332 3888 Venezuela 58-2-953-6861 Online Help Users can download drivers, patches, and Compaq service updates from the following sources: CompuServe Prodigy America Online Internet: Questions can be submitted to Compaq Technical Support staff using the electronic mail address: support@compaq.com .
Page 14: Compaq Prosignia 200 Features
Chapter 1 Compaq ProSignia 200 Features The Compaq ProSignia 200 server uses high-performance processor and I/O technologies to give you maximum performance and flexibility. It is the only server that delivers true server functionality at the price of a desktop PC.
Page 15: Comprehensive Customer Support
Compaq servers for advanced networks. You can print TechNotes from the Systems Reference Library CD. Standard Features The following features are standard on all Compaq ProSignia 200 models, unless otherwise noted. Front Panel Components The following illustration and table show and describe the components on the front panel of the server.
Page 16: Removing The Side Access Panel
4. Slide the side access panel toward the rear of the unit. 5. Lift and remove the panel. Compaq ProSignia 200 Server Reference Guide Writer: Project: Compaq ProSignia 200 Features Comments: File Name: C-ch1.doc Last Saved On: 4/14/97 11:03 AM...
Page 17: Replacing The Side Access Panel
These panels are an integral part of the cooling system and removing them while the system is running may adversely affect data integrity. Writer: Project: Compaq ProSignia 200 Features Comments: File Name: C-ch1.doc Last Saved On: 4/14/97 11:03 AM...
Page 18: Removing The Front Bezel
3. Rotate the bezel out to about 45 degrees, then pull to remove the bezel from the chassis. Compaq ProSignia 200 Server Reference Guide Writer: Project: Compaq ProSignia 200 Features Comments: File Name: C-ch1.doc Last Saved On: 4/14/97 11:03 AM...
Page 19: Rear Panel Connectors
The following illustration and table show and describe the connectors and switches on the rear panel of the server. Each connector includes an icon to help you identify its function. Writer: Project: Compaq ProSignia 200 Features Comments: File Name: C-ch1.doc Last Saved On: 4/14/97 11:03 AM...
Page 20 (earthed) outlet. The grounding type plug is an important safety feature. To avoid the risk of electrical shock or damage to your equipment, do not disable this feature Figure 1-6. ProSignia 200 rear panel connectors and switches Table 1-2 Rear Panel Connectors Connector...
Page 21: Drive Positions
NetFlex-3/P (RJ45 (10BaseT) and 10Base2 (BNC) supported) No network controller present Drive Positions The ProSignia 200 server can house up to four mass storage devices. The following table and illustration describe the recommended drive configurations. Writer: Project: Compaq ProSignia 200 Features Comments:...
Page 22: Processor Board
......Figure 1-7. ProSignia 200 server drive positions Table 1-3 Description of Drive Bays...
Page 23: Cache Memory
(two 8-MB SIMMs) of EDO memory. IMPORTANT: ECC-capable FastPage Mode (FPM) memory can be purchased as an option kit from Compaq. The ProSignia 200 does not support the mixing of EDO and FPM memory . For information on upgrading memory, see Chapter 3, “Installing Hardware Options.”...
Page 24: Network Controller
......1-11 Network Controller 32-Bit, Compaq Netelligent, 10 T PCI UTP controller on the PCI local bus. Features of the controller include the RJ-45 connector for 10BaseT Ethernet. Network controllers will vary by country models. Your server will be...
Page 25: Server Management And Configuration
Compaq ProSignia 200 Features Server Management and Configuration Compaq offers an extensive set of features and optional tools to support effective server management and configuration. These features fall into the categories listed below and are described in this guide: SmartStart...
Page 26: Automatic Server Recovery-2 (Asr-2)
Power Switch Cover Security Feature See Chapter 6, “Using Security Management,” for more information on these security features. Compaq ProSignia 200 Server Reference Guide Writer: Project: Compaq ProSignia 200 Features Comments: File Name: C-ch1.doc Last Saved On: 4/14/97 11:03 AM...
Page 27: Getting Additional Configuration Information
1-14 Compaq ProSignia 200 Features Getting Additional Configuration Information The latest product updates are available on the Internet at the Compaq World Wide Web site. Access the site through the following address: http://www.compaq.com From the Compaq Home Page, select Product.
Page 28: Server Management
......Chapter 2 Server Management Compaq server management features provide monitoring, analysis, and control of the fault tolerance, performance, and configuration aspects of the servers. These server management features include:...
Page 29: Environment
If your server has an external SCSI storage subsystem, the storage chassis thermal environment can be monitored to alert the Insight Manager console when the subsystem’s temperature exceeds the factory preset temperature threshold. Writer: Compaq Computer Corporation Project: Server Management Comments: File Name: D-ch2.doc Last Saved On: 4/14/97 11:14 AM...
Page 30: Network Fault Prevention Tracking
Memory Fault Prevention Tracking If you purchase the ECC-capable option upgrade kit from Compaq, your server tracks the operation of the ECC memory subsystem, looking for any correctable memory errors. This allows you to schedule maintenance to either avert or recover from impending ECC memory failures.
Page 31: Server Health Logs
You can view the Critical Error Log through the Inspect Utility, Diagnostics Utility, or Insight Manager. The Diagnostics Utility either resolves the error or suggests corrective action. Writer: Compaq Computer Corporation Project: Server Management Comments: File Name: D-ch2.doc Last Saved On: 4/14/97 11:14 AM...
Page 32 Each error type is briefly explained below. If you encounter any of these errors, run the Diagnostics Utility. Not all error messages are applicable to the ProSignia 200. Table 2- 1 Critical Error Log Messages...
Page 33 NMI - Fail-Safe Timer Expiration Software was unable to reset the system fail-safe timer, resulting in a server failure. continued Writer: Compaq Computer Corporation Project: Server Management Comments: File Name: D-ch2.doc Last Saved On: 4/14/97 11:14 AM...
Page 34 Accompanying data indicates if an auto-shutdown sequence has been invoked or if the battery has been nearly depleted. Compaq ProSignia 200 Server Reference Guide Writer: Compaq Computer Corporation Project: Server Management Comments: File Name: D-ch2.doc Last Saved On: 4/14/97 11:14 AM...
Page 35 System Board Revision Assembly Version Functional Revision Level Processor 01 Revision Assembly Version Functional Revision Level Slot 05 Revision Assembly Version Functional Revision Level continued Writer: Compaq Computer Corporation Project: Server Management Comments: File Name: D-ch2.doc Last Saved On: 4/14/97 11:14 AM...
Page 36 Complete version information is kept on the previous configuration, which allows you to correlate hardware changes with server failure. Compaq ProSignia 200 Server Reference Guide Writer: Compaq Computer Corporation Project: Server Management Comments: File Name: D-ch2.doc Last Saved On: 4/14/97 11:14 AM...
Page 37: Storage Fault Recovery Tracking
(with the option upgrade kit). Automatic Server Recovery-2 Automatic Server Recovery-2 (ASR-2) lets the server restart automatically from the operating system or the Compaq Utilities. To use this feature, you must use the System Configuration Utility to install Compaq Utilities in the system partition.
Page 38 ASR-2 tries to restart the server up to 10 times. If ASR-2 cannot restart the server within 10 attempts, it places a critical error in the Critical Error Log, starts the server into Compaq Utilities, and enables remote access (if you configured remote access).
Page 39 If you have configured the Compaq Utilities for network access, you can access the utilities over the network. You can use Insight Manager for dial-in or network access.
Page 40 ......2-13 You may also run Compaq Utilities remotely over an IPX or IP network using the Network feature: To use Compaq Utilities on an IPX network, you must have Compaq Insight Manager 2.0 or later or an NVT (Novell Virtual Terminal)
Page 41 20 or 30 minutes, giving you time to arrive at the server and diagnose the problem. The Compaq Health Driver is independent of the ASR-2 timer. You can load it without enabling the ASR-2 timer. This allows the driver to log information in the Server Health Logs without restarting the server if a critical error occurs.
Page 42 The following ASR-2 flow chart shows you the sequence of events after a hardware or software error occurs: Figure 2- 1. ASR-2 flow chart Compaq ProSignia 200 Server Reference Guide Writer: Compaq Computer Corporation Project: Server Management Comments: File Name: D-ch2.doc Last Saved On: 4/14/97 11:14 AM...
Page 43 Server Management Booting into Compaq Utilities When you enable ASR-2 to start into Compaq Utilities and a critical error occurs, the operating-system-specific Health Driver logs the error information in the Critical Error Log and the ASR-2 feature restarts the server. When the system reinitializes, the system pages the designated administrator (if enabled), and starts Compaq Utilities from the hard drive.
Page 44 Enabled. Do not test the pager if you are running remotely and are using only one modem. continued Compaq ProSignia 200 Server Reference Guide Writer: Compaq Computer Corporation Project: Server Management Comments: File Name: D-ch2.doc Last Saved On: 4/14/97 11:14 AM...
Page 45 Boot Compaq Utilities. When the system starts because of an ASR reset, it starts to the Compaq Utilities, sets the Management Modem to auto-answer, and waits for the administrator to dial in and run the Compaq Utilities.
Page 46 Network IP address, Network IP net mask, and Network IP router address. When the system restarts to the Compaq Utilities because of an ASR reset, it loads IP network support. This enables remote access via Telnet.
Page 47 NET.CFG file that you load into the system partition. If you configure the server to boot into Compaq Utilities, the server prepares for remote communications, so you can remotely run Diagnostics software, Inspect Utility, or System Configuration Utility using a workstation running terminal emulation software, such as Insight Manager or PC Anywhere.
Page 48 10 times. If the ASR-2 feature cannot restart the server within 10 attempts, it logs a critical error in the Critical Error Log, restarts the server into the Compaq Utilities, and puts the modem into auto-answer mode. Your System Configuration Utility setting should resemble the following when...
Page 49 During ASR-2, the system does not prompt for the Power-On Password. This allows the ASR-2 to restart the operating system or Compaq Utilities without user intervention. To maintain system security, set the server to boot in Network Server Mode (an option in the System Configuration Utility).
Page 50: Remote Service Features
Provides remote diagnostic capability after you configure ASR-2 and the Diagnostics reset restart option to restart from Compaq Utilities. Also allows you to view Health Logs. Disk-based diagnostics can also be run locally. Press F10 during the restart process when the cursor moves to the upper-right corner of the monitor.
Page 51: Rompaq
2-24 Server Management ROMPaq Using flash ROM in Compaq servers allows the firmware (BIOS) to be upgraded with system or option ROMPaq utilities. To upgrade the ROM, Run the ROMPaq utility from the system partition Insert a ROMPaq diskette into drive A and cold boot the system.
Page 52: Installing Hardware Options
To reduce the risk of personal injury from hot surfaces, allow the internal system components to cool before touching. Compaq ProSignia 200 Server Reference Guide Writer: Compaq Computer Corporation Project: Installing Hardware Options Comments: File Name: E-ch3.doc Last Saved On: 4/14/97 11:21 AM...
Page 53: Pre-Failure Warranty
Refer to Appendix C, “Electrostatic Discharge,” for more information. Pre-Failure Warranty If you purchase the optional ECC feature from Compaq, your server includes the Pre-Failure Warranty for hard drives and SIMMs that were purchased from Compaq through an Authorized Compaq Reseller. Supported components are...
Page 54: Disabling The Power Switch Cover Security Feature
Figure 3-1. Removing the power switch from the front bezel Compaq ProSignia 200 Server Reference Guide Writer: Compaq Computer Corporation Project: Installing Hardware Options Comments: File Name: E-ch3.doc Last Saved On: 4/14/97 11:21 AM...
Page 55: Installing Expansion Boards
9. Replace the Side Access Panel. Installing Expansion Boards The ProSignia 200 server contains five expansion slots: Two dedicated PCI local bus expansion slots (slots 1 and 2) One shared slot, either PCI or ISA (slot 3); (PCI occupied by NIC)
Page 56: Removing The Expansion Backplane Brace
......PCI and ISA expansion boards can be installed in the following expansion board slot locations: Figure 3-3. Locating ProSignia 200 expansion board slots Removing the Expansion Backplane Brace CAUTION:...
Page 57: Removing An Expansion Slot Cover
To install a PCI or an ISA expansion board, complete the following steps: 1. Locate the correct vacant slot in the expansion board. Writer: Compaq Computer Corporation Project: Installing Hardware Options Comments: File Name: E-ch3.doc Last Saved On: 4/14/97 11:21 AM...
Page 58: Installing An Expansion Board
Compaq ProSignia 200 Server Reference Guide Writer: Compaq Computer Corporation Project: Installing Hardware Options Comments: File Name: E-ch3.doc Last Saved On: 4/14/97 11:21 AM...
Page 59: Replacing The Expansion Backplane Brace
1. Grasp the expansion backplane brace at both ends and push it into the server chassis. Use care when guiding the assembly into the unit to prevent damaging the boards. Writer: Compaq Computer Corporation Project: Installing Hardware Options Comments: File Name: E-ch3.doc Last Saved On: 4/14/97 11:21 AM...
Page 60 Compaq ProSignia 200 Server Reference Guide Writer: Compaq Computer Corporation Project: Installing Hardware Options Comments: File Name: E-ch3.doc Last Saved On: 4/14/97 11:21 AM...
Page 61: Installing A Processor Upgrade In Your Prosignia 200 Server
CAUTION: Installing the processor upgrade incorrectly may cause damage to the processor board. Compaq recommends that you have a Compaq Authorized Reseller or Service Provider install the processor upgrade. If you plan to install it yourself, read all the instructions carefully before you begin.
Page 62 7. Grasp the back edge of the system board tray and slide it out of the chassis. Compaq ProSignia 200 Server Reference Guide Writer: Compaq Computer Corporation Project: Installing Hardware Options Comments: File Name: E-ch3.doc Last Saved On: 4/14/97 11:21 AM...
Page 63: Removing The Processor
Figure 3-9. Removing the processor 2. Lift the heat sink and thermal pad off the processor. Figure 3-10. Removing the processor heat sink and thermal pad Writer: Compaq Computer Corporation Project: Installing Hardware Options Comments: File Name: E-ch3.doc Last Saved On: 4/14/97 11:21 AM...
Page 64: Installing The Processor
ZIF socket. CAUTION: The thermal pad must be installed or damage will occur to your processor. Compaq ProSignia 200 Server Reference Guide Writer: Compaq Computer Corporation Project: Installing Hardware Options Comments: File Name: E-ch3.doc Last Saved On: 4/14/97 11:21 AM...
Page 65: Installing Hardware Options
Figure 3-12. Installing the processor 4. Install the heat sink and the heat sink retaining clip. Figure 3-13. Installing the processor thermal pad and heat sink Writer: Compaq Computer Corporation Project: Installing Hardware Options Comments: File Name: E-ch3.doc Last Saved On: 4/14/97 11:21 AM...
Page 66: Installing A Video Memory Upgrade
Figure 3-14. Installing the heat sink clip Installing a Video Memory Upgrade The ProSignia 200 has a Cirrus 5436 PCI performance graphics controller integrated on the system board. The maximum memory upgrade is 1 megabyte of EDO DRAM for a total of 2 megabytes of EDO DRAM.
Page 67 5. Replace the expansion board cage and the side access panel. 6. Change the video resolution to take advantage of the additional display modes now available with the upgraded memory. Writer: Compaq Computer Corporation Project: Installing Hardware Options Comments: File Name: E-ch3.doc Last Saved On: 4/14/97 11:21 AM...
Page 68: Adding Memory To The Prosignia 200
The system comes preinstalled with EDO memory. Options may be purchased to upgrade the system to 128-MB of EDO memory. When the ProSignia 200 is using EDO memory, all ECC functions will be turned off.
Page 69: Installing Simms
......3-18 Installing Hardware Options Figure 3-16. Four memory sockets on the ProSignia 200 Pentium-based system board Table 3-1 ProSignia 200 Memory Upgrade...
Page 70: Installing Mass Storage Devices
Your server recognizes system memory upgrades and automatically reconfigures the server. Installing Mass Storage Devices The ProSignia 200 server supports up to five internal drives. They may be installed in various configurations. Compaq ProSignia 200 Server Reference Guide Writer: Compaq Computer Corporation Project: Installing Hardware Options Comments:...
Page 71 NOTE: Installing a third-party hard drive requires the use of the special Compaq flanged screws stored in the front of the server frame. Writer: Compaq Computer Corporation Project: Installing Hardware Options Comments: File Name: E-ch3.doc Last Saved On: 4/14/97 11:21 AM...
Page 72 Installing a Mass Storage Device in the Removable Media Area To install a mass storage device in the removable media area: Figure 3-18. ProSignia 200 removable media bays 2, 3, 4, and 5 Table 3-2 Mass Storage Bay Locator Position...
Page 73: Installing A 3.5-Inch Drive Into A 5.25-Inch Drive Bay
Install the guide screw in the middle hole on 3.5-inch drives (drive bays 2, 3, and 4). Install the guide screw in the front hole on 5.25-inch drives. Compaq has provided extra guide screws, installed in the front of the server chassis, under the front bezel. Installing a 3.5-Inch Drive into a 5.25-Inch Drive Bay...
Page 74 4. Install the guide screw in the front screw hole on the right side of the bracket. Figure 3-20. Installing the guide screw in the drive bracket Compaq ProSignia 200 Server Reference Guide Writer: Compaq Computer Corporation Project: Installing Hardware Options Comments: File Name: E-ch3.doc Last Saved On: 4/14/97 11:21 AM...
Page 75 6. Connect the drive power and signal cables. Figure 3-22. Connecting the drive cables 7. Remove the blank drive bezel from the inside of the front bezel, if necessary. Writer: Compaq Computer Corporation Project: Installing Hardware Options Comments: File Name: E-ch3.doc Last Saved On: 4/14/97 11:21 AM...
Page 76: Connecting The Power Cord And Peripheral Devices
If the AC Voltage Selector Switch is not properly set, the server will be damaged when power is applied. Compaq ProSignia 200 Server Reference Guide Writer: Compaq Computer Corporation Project: Installing Hardware Options Comments: File Name: E-ch3.doc Last Saved On: 4/14/97 11:21 AM...
Page 77: Prosignia 200 Rear Panel Connectors
When unplugging cords from the electrical outlet, grasp the cord by the plug. ProSignia 200 Rear Panel Connectors Figure 3-23. ProSignia 200 rear panel connectors and switches Writer: Compaq Computer Corporation Project: Installing Hardware Options Comments: File Name: E-ch3.doc Last Saved On: 4/14/97 11:21 AM...
Page 78: Using The System Configuration Utility
Inspect Utilities If the SmartStart and Support Software CD is used the first time the server is configured, the SmartStart program automatically creates a system partition and installs the System Configuration Utility and other Compaq utilities in that partition. IMPORTANT: This Compaq system utilities partition should not be confused with the partition(s) created by your operating system.
Page 79: Resolving Resource Conflicts
The .CFG files provide information such as switch settings, IRQs, and software installation guidelines. The .CFG files for Compaq computers are located on the System Configuration diskettes and the SmartStart and Support Software CD (SmartStart CD).
Page 80: Starting The System Configuration Utility
Starting the System Configuration Utility To start the Compaq System Configuration Utility for the first time, refer to the SmartStart Installation poster. After the SmartStart and Support Software CD is used for the first time to...
Page 81: System Configuration Menu
When you select the Configure Hardware menu, a screen with five steps displays. Following is a brief explanation of each step. Writer: Compaq Computer Corporation Project: Using the System Configuration Utility Comments: File Name: F-ch4.doc Last Saved On: 4/14/97 11:43 AM...
Page 82 Then adjust the switch and jumper settings on each board to match the settings displayed on the screen. Compaq ProSignia 200 Server Reference Guide Writer: Compaq Computer Corporation Project: Using the System Configuration Utility Comments: File Name: F-ch4.doc Last Saved On: 4/14/97 11:43 AM...
Page 83: System Partition
The following menu options are available: Create System Partition Upgrade System Partition Delete System Partition Copy Files Delete Files Writer: Compaq Computer Corporation Project: Using the System Configuration Utility Comments: File Name: F-ch4.doc Last Saved On: 4/14/97 11:43 AM...
Page 84: Creating A New System Partition
Use this procedure if SmartStart was not used to configure your server. To create a system partition, follow this procedure: 1. Insert the Compaq SmartStart and Support Software CD in the CD-ROM drive and turn on the server. IMPORTANT: The system partition requires about 32 MB of disk space at the beginning of the hard drive and an unused entry in the boot record.
Page 85: Upgrading The System Partition
Using the System Configuration Utility Upgrading the System Partition To upgrade the system partition, follow this procedure: 1. Insert the Compaq SmartStart and Support Software CD in the CD-ROM drive and turn on the computer. 2. Select Upgrade System Partition.
Page 86: Configuring Pci Boards Automatically
Also, you may use the System Configuration Utility to change the default automatic settings. Compaq ProSignia 200 Server Reference Guide Writer: Compaq Computer Corporation Project: Using the System Configuration Utility Comments: File Name: F-ch4.doc Last Saved On: 4/14/97 11:43 AM...
Page 87: Removing Boards
You can still configure your server and manually install your operating system. Some operating systems have an integrated installation using the operating system manufacturer’s CDs. Writer: Compaq Computer Corporation Project: Using the System Configuration Utility Comments: File Name: F-ch4.doc Last Saved On: 4/14/97 11:43 AM...
Page 88: Loading Compaq Device Drivers
......4-11 Loading Compaq Device Drivers Drivers are located on the Support Software Diskettes and on the Compaq SmartStart and Support Software CD. The drivers on the Support Software Diskettes may be newer versions with new functionality and upgraded utilities.
Page 89 Please read NET_SRVR.RDM from the NPFC diskettes for further information. 3. Your ProSignia 200 server comes with two IDE channels to which you can attach IDE devices. For each IDE channel to which you have an attached device, you must load the following drivers found on the NPFC diskette, according to the type of device attached: LOAD A:\IDE\IDEATA.HAM for each IDE channel.
Page 90: Windows Nt Device Drivers From Compaq
You can also obtain the 312PT9.EXE patch off the Compaq SmartStart NetWare CD No. 3 under: \PATCHES\NW312 5. If you are running NetWare 3.12 on your ProSignia 200 system, you must run the NWPA_312.BAT file. This file is located in the \NWPA subdirectory of the NPFC diskette.
Page 91: Sco Openserver And Sco Unixware Device Drivers From Compaq
2. Alternatively, by booting the SmartStart CD and choosing a manual installation path, you can use the SCO UNIX from Compaq CDs to install your SCO software. This will also automatically install all the drivers your server needs while presenting the more familiar SCO interview process instead of the SmartStart interview process.
Page 92: Sco Openserver
Compaq EFS contains a bootable documentation diskette. Before attempting to install the SCO UNIX software, boot this diskette and read the README file for the Compaq EFS. It tells you how to use the boot time loadable driver diskettes along with the SCO installation media.
Page 93: Ibm Os/2 Device Drivers From Compaq
Your server must have certain device drivers for some server options to operate using IBM OS/2 Warp Server 4.0, OS/2 Warp, OS/2 Warp Connect 3.0, and OS/2 2.x. These drivers are located on the Compaq SmartStart CD you received with your server. If you use SmartStart to install your operating system, these drivers are loaded automatically.
Page 94: Diagnostics And Other Utilities
......4-17 These drivers are located on the Compaq SmartStart and Support Software CD you received with your server. You can use SmartStart to create a Banyan VINES Support Software Diskette (SSD) from Compaq to support a manual installation of Banyan VINES.
Page 95: Using The Cd-Rom Drive
680 megabytes of digital information. Figure 5- 1. Identifying CD-ROM drive lights and switches Compaq ProSignia 200 Server Reference Guide Writer: Compaq Computer Corporation Project: Using the CD-ROM Drive Comments: File Name: G-ch5.doc Last Saved On: 1/28/97 1:29 PM...
Page 96: Opening The Tray Automatically
1. With your server turned on, open the CD-ROM tray by pressing the eject button on the front panel of the drive. Writer: Compaq Computer Corporation Project: Using the CD-ROM Drive Comments: File Name: G-ch5.doc Last Saved On: 1/28/97 1:29 PM...
Page 97 4. When the busy indicator turns green, the drive is ready to receive commands and data may be retrieved from the disk. Compaq ProSignia 200 Server Reference Guide Writer: Compaq Computer Corporation Project: Using the CD-ROM Drive Comments: File Name: G-ch5.doc Last Saved On: 1/28/97 1:29 PM...
Page 98: Opening The Tray Manually
Figure 5- 3. Opening the CD-ROM tray manually 2. Slowly pull the tray out from the drive until the tray is fully extended, then remove the disk. Writer: Compaq Computer Corporation Project: Using the CD-ROM Drive Comments: File Name: G-ch5.doc Last Saved On: 1/28/97 1:29 PM...
Page 99: Cd-Rom Drive Care And Safety Precautions
Safety If any object or liquid falls into the CD-ROM drive, immediately unplug the server and have it checked by an Authorized Compaq Service Provider. Compaq ProSignia 200 Server Reference Guide Writer: Compaq Computer Corporation Project: Using the CD-ROM Drive Comments:...
Page 100: Using Security Management
......Chapter 6 Using Security Management Compaq ProSignia servers offer multilevel security to provide just the right solution for your security needs. This comprehensive security system implements control on three levels: software, hardware, and mechanical.
Page 101 Can also be used to secure the server to a fixed secure the server to a fixed object. object. Writer: Compaq Computer Corporation Project: Using Security Management Comments: File Name: H-ch6.doc Last Saved On: 4/14/97 11:56 AM...
Page 102: Accessing The System Configuration Utility
When you turn on the server, a Power-On Password screen appears. You must enter the valid password before you can continue the boot sequence. Compaq ProSignia 200 Server Reference Guide Writer: Compaq Computer Corporation Project: Using Security Management Comments: File Name: H-ch6.doc Last Saved On: 4/14/97 11:56 AM...
Page 103: Administrator Password
4. Type your password and press Enter. You will be asked to verify the password before it is set. 5. Press F10 to return to the Steps menu. 6. Select Step 5: Save and exit. Writer: Compaq Computer Corporation Project: Using Security Management Comments: File Name: H-ch6.doc Last Saved On: 4/14/97 11:56 AM...
Page 104: Entering The Password
3. The new password takes effect the next time you turn on the server. Compaq ProSignia 200 Server Reference Guide Writer: Compaq Computer Corporation Project: Using Security Management Comments: File Name: H-ch6.doc Last Saved On: 4/14/97 11:56 AM...
Page 105: Deleting The Password
NOTE : The jumper at E6 pin 6-7 must be moved back from pins 6-7 to pins 5-6 to re-enable the Power-On and Administrator Passwords. Writer: Compaq Computer Corporation Project: Using Security Management Comments: File Name: H-ch6.doc Last Saved On: 4/14/97 11:56 AM...
Page 106: Quicklock
QuickLock hot key combination Ctrl+Alt+L disables the keyboard and the pointing device interface. Compaq ProSignia 200 Server Reference Guide Writer: Compaq Computer Corporation Project: Using Security Management Comments: File Name: H-ch6.doc Last Saved On: 4/14/97 11:56 AM...
Page 107: Diskette Drive Controls
3. Set switch 1 on SW2 on the riser board to the on/closed position to turn on the feature. 4. Replace the side access panel and turn on the server. The feature is now enabled. Writer: Compaq Computer Corporation Project: Using Security Management Comments: File Name: H-ch6.doc Last Saved On: 4/14/97 11:56 AM...
Page 108: Serial/Parallel Interface Control
These control features enable and disable the serial and parallel interfaces. Disabling the serial and parallel interfaces prevents data from being transferred through these interfaces. Compaq ProSignia 200 Server Reference Guide Writer: Compaq Computer Corporation Project: Using Security Management Comments: File Name: H-ch6.doc Last Saved On: 4/14/97 11:56 AM...
Page 109: Upgrading The Rom
6-10 Using Security Management Upgrading the ROM Your Compaq server comes with reprogrammable flash ROM. If you want to upgrade your ROM, you may order an upgraded ROMPaq diskette from Compaq. ROMPaq firmware upgrades are also available on the Compaq Internet site at http://www.compaq.com.
Page 110: Security Lock
The following figure illustrates the security lock provision: Figure 6- 3. Securing the system Compaq ProSignia 200 Server Reference Guide Writer: Compaq Computer Corporation Project: Using Security Management Comments: File Name: H-ch6.doc Last Saved On: 4/14/97 11:56 AM...
Page 111: Maintaining And Shipping The Server
Keep liquids away from the server and the keyboard. Compaq ProSignia 200 Server Reference Guide Writer: Compaq Computer Corporation Project: Maintaining and Shipping the Server Comments: File Name: I-ch7.doc Last Saved On: 4/14/97 12:02 PM...
Page 112: Preparations For Shipping
4. Disconnect the AC power cord from the AC outlet, then from the server. 5. Disconnect the system components and external devices from their power sources, then from the server. Writer: Compaq Computer Corporation Project: Maintaining and Shipping the Server Comments: File Name: I-ch7.doc Last Saved On: 4/14/97 12:02 PM...
Page 113 6. To protect the server components and external devices, pack them in their original packing boxes or similar packaging with sufficient packing material. Compaq ProSignia 200 Server Reference Guide Writer: Compaq Computer Corporation Project: Maintaining and Shipping the Server Comments: File Name: I-ch7.doc Last Saved On: 4/14/97 12:02 PM...
Page 114: Diagnostics Tools
ROMPaq utilities to upgrade flash ROMs Automatic Server Recovery (ASR-2) Power-On Self-Test (POST) POST is a series of diagnostic tests that run automatically on Compaq servers when the system is turned on. POST checks the following assemblies to ensure that the server is functioning properly:...
Page 115 POST or after resetting the system, follow the instructions in the table below. The error messages and codes listed in this table include all codes generated by Compaq products. Your system generates only those codes that are applicable to your configuration and options.
Page 116 Run the System Readable ID Yields that should contain an ISA Configuration Utility Valid ID board. and correct. continued Compaq ProSignia 200 Server Reference Guide Writer: Compaq Computer Corporation Project: Diagnostics Tools Comments: File Name: J-ch8.doc Last Saved On: 4/14/97 12:05 PM...
Page 117 Cache controller failure Run Diagnostics. Error 207-Invalid Memory None Memory module installed Verify placement of Configuration - Check incorrectly memory modules. DIMM [SIMM] Installation continued Writer: Compaq Computer Corporation Project: Diagnostics Tools Comments: File Name: J-ch8.doc Last Saved On: 4/14/97 12:05 PM...
Page 118 Contact your service provider. 301-Keyboard Error None Keyboard failure Turn off the computer, then reconnect the keyboard. continued Compaq ProSignia 200 Server Reference Guide Writer: Compaq Computer Corporation Project: Diagnostics Tools Comments: File Name: J-ch8.doc Last Saved On: 4/14/97 12:05 PM...
Page 119 Configuration Utility. Conflict parallel port X. 402-Monochrome 1L,2S Monochrome display Replace the Adapter Failure controller monochrome display controller. continued Writer: Compaq Computer Corporation Project: Diagnostics Tools Comments: File Name: J-ch8.doc Last Saved On: 4/14/97 12:05 PM...
Page 120 Configuration not been detected Utility and correct. 2. Replace the coprocessor. continued Compaq ProSignia 200 Server Reference Guide Writer: Compaq Computer Corporation Project: Diagnostics Tools Comments: File Name: J-ch8.doc Last Saved On: 4/14/97 12:05 PM...
Page 121 Contact your service power. provider. 1701-SCSI Controller None A test on the Fast SCSI-2 Contact your service failure Controller failed provider. continued Writer: Compaq Computer Corporation Project: Diagnostics Tools Comments: File Name: J-ch8.doc Last Saved On: 4/14/97 12:05 PM...
Page 122 Fixed disk drive error Run the System does not support Configuration Utility DMA Mode and correct. continued Compaq ProSignia 200 Server Reference Guide Writer: Compaq Computer Corporation Project: Diagnostics Tools Comments: File Name: J-ch8.doc Last Saved On: 4/14/97 12:05 PM...
Page 123 1761-Fixed Disk 1 None Fixed disk drive error. Run the System does not support Configuration Utility Block Mode and correct. continued Writer: Compaq Computer Corporation Project: Diagnostics Tools Comments: File Name: J-ch8.doc Last Saved On: 4/14/97 12:05 PM...
Page 124 1766- Slot x Drive Array requires System ROM Upgrade. Run Run the latest Systems Systems ROMPaq Utility ROMPaq Utility to upgrade your System ROMs. continued Compaq ProSignia 200 Server Reference Guide Writer: Compaq Computer Corporation Project: Diagnostics Tools Comments: File Name: J-ch8.doc Last Saved On: 4/14/97 12:05 PM...
Page 125 Select F2 to data loss and re- accept data loss and enable the logical to re-enable logical drives. Restore data drives. from backup. continued Writer: Compaq Computer Corporation Project: Diagnostics Tools Comments: File Name: J-ch8.doc Last Saved On: 4/14/97 12:05 PM...
Page 126 External and internal SCSI Reconfigure drives. SCSI Port Termination drives are both configured Error to Port 1. continued Compaq ProSignia 200 Server Reference Guide Writer: Compaq Computer Corporation Project: Diagnostics Tools Comments: File Name: J-ch8.doc Last Saved On: 4/14/97 12:05 PM...
Page 127 1782-Disk Controller None Hard disk drive circuitry Run Diagnostics. Failure error Replace failed assembly or contact your service provider. continued Writer: Compaq Computer Corporation Project: Diagnostics Tools Comments: File Name: J-ch8.doc Last Saved On: 4/14/97 12:05 PM...
Page 128 Interim Data Recovery mode. continued Compaq ProSignia 200 Server Reference Guide Writer: Compaq Computer Corporation Project: Diagnostics Tools Comments: File Name: J-ch8.doc Last Saved On: 4/14/97 12:05 PM...
Page 129 If this message was not caused by a bad power cable connection, and no drive replacement took place, this could indicate noise on the data cable. Check cable for proper routing. continued Writer: Compaq Computer Corporation Project: Diagnostics Tools Comments: File Name: J-ch8.doc Last Saved On: 4/14/97 12:05 PM...
Page 130 Hard drive error or wrong Run the System Configuration Error drive type Configuration Utility and Diagnostics. continued Compaq ProSignia 200 Server Reference Guide Writer: Compaq Computer Corporation Project: Diagnostics Tools Comments: File Name: J-ch8.doc Last Saved On: 4/14/97 12:05 PM...
Page 131 36 Array Accelerator is power-on hours.. temporarily disabled. Array Accelerator will be reenabled when battery reaches full charge. continued Writer: Compaq Computer Corporation Project: Diagnostics Tools Comments: File Name: J-ch8.doc Last Saved On: 4/14/97 12:05 PM...
Page 132 Read Error Occurred. writes memory. Data in Array Accelerator has been lost. Array Accelerator is disabled. continued Compaq ProSignia 200 Server Reference Guide Writer: Compaq Computer Corporation Project: Diagnostics Tools Comments: File Name: J-ch8.doc Last Saved On: 4/14/97 12:05 PM...
Page 133 Configuration Utility - occurred during POST. System Configuration F10 key) Utility. (RESUME - F1 KEY) None As indicated to continue. Press the F1 key. Writer: Compaq Computer Corporation Project: Diagnostics Tools Comments: File Name: J-ch8.doc Last Saved On: 4/14/97 12:05 PM...
Page 134: Diagnostics Utility
From the System Partition. From diskette. A diskette can be created from the SmartStart and Support Software CD. Compaq ProSignia 200 Server Reference Guide Writer: Compaq Computer Corporation Project: Diagnostics Tools Comments: File Name: J-ch8.doc Last Saved On: 4/14/97 12:05 PM...
Page 135: Diagnostic Error Codes
6. The Diagnostics Utility prompts you and suggests corrective action. Diagnostic Error Codes The Diagnostic error codes and recommended actions are listed in the following tables. Writer: Compaq Computer Corporation Project: Diagnostics Tools Comments: File Name: J-ch8.doc Last Saved On: 4/14/97 12:05 PM...
Page 136 IMPORTANT: This information is intended for the user's reference only. Many of the corrective actions involve complex hardware and/or software changes and should be performed only by an Authorized Compaq Service Provider. 100 Series - Primary Processor Test Error Codes The 100 series of Diagnostic error codes identify failures with processor and system board functions.
Page 137: Series - Memory Test Error Codes
Keyboard Test Error Codes Error Code Range Possible Corrective Action 301-xx ... 304-xx The keyboard or the system board may require replacement. Writer: Compaq Computer Corporation Project: Diagnostics Tools Comments: File Name: J-ch8.doc Last Saved On: 4/14/97 12:05 PM...
Page 138: 400 Series - Parallel Printer Test Error Codes
The diskette drive or system board may require replacement. 699-xx 1. Replace the diskette and retest. 2. Run the System Configuration Utility. Compaq ProSignia 200 Server Reference Guide Writer: Compaq Computer Corporation Project: Diagnostics Tools Comments: File Name: J-ch8.doc Last Saved On: 4/14/97 12:05 PM...
Page 139: 1100 Series - Serial Test Error Codes
1200-xx ... 1210-xx Refer to the modem documentation for correct setup procedures. Poor line quality may cause errors. The modem may require replacement Writer: Compaq Computer Corporation Project: Diagnostics Tools Comments: File Name: J-ch8.doc Last Saved On: 4/14/97 12:05 PM...
Page 140: 1700 Series - Fixed Disk Drive Test Error Codes
The tape drive, the tape adapter board, or the system board may require replacement. Compaq ProSignia 200 Server Reference Guide Writer: Compaq Computer Corporation Project: Diagnostics Tools Comments: File Name: J-ch8.doc Last Saved On: 4/14/97 12:05 PM...
Page 141: 2400 Series - Advanced Vga Board Test Error Codes
Possible Corrective Action 6000-xx ... 6089-xx Run the System Configuration Utility. Loose or defective cable connections may cause error messages. The controller may require replacement. Writer: Compaq Computer Corporation Project: Diagnostics Tools Comments: File Name: J-ch8.doc Last Saved On: 4/14/97 12:05 PM...
Page 142: 6500 Series - Scsi Fixed Disk Drive Test Error Codes
The CD-ROM drive, the CD-ROM adapter board, or the system board may require replacement. Compaq ProSignia 200 Server Reference Guide Writer: Compaq Computer Corporation Project: Diagnostics Tools Comments: File Name: J-ch8.doc Last Saved On: 4/14/97 12:05 PM...
Page 143: 6700 Series - Scsi Tape Drive Test Error Codes
7061-xx ... 7062-xx The Server Manager/R board Voice ROM may require replacement. 7078-xx ... 7079-xx The Server Manager/R board battery may require replacement. Writer: Compaq Computer Corporation Project: Diagnostics Tools Comments: File Name: J-ch8.doc Last Saved On: 4/14/97 12:05 PM...
Page 144: 8600 Series - Pointing Device Interface Test Error Codes
IMPORTANT: Run Test Computer and have the printed report available before placing a call to the Compaq Customer Support Center or your local Compaq Service Provider. Compaq ProSignia 200 Server Reference Guide Writer: Compaq Computer Corporation Project: Diagnostics Tools Comments: File Name: J-ch8.doc Last Saved On: 4/14/97 12:05 PM...
Page 145: Diagnostics Tools
You can choose how many times to run the tests, to stop on errors, or to print or file a log of errors. Writer: Compaq Computer Corporation Project: Diagnostics Tools Comments: File Name: J-ch8.doc Last Saved On: 4/14/97 12:05 PM...
Page 146: Inspect Computer
IMPORTANT: When you run Test, be sure to record the error message numbers and have them available when you contact your Authorized Compaq Reseller or Service Provider. 8. Follow the instructions on the screen as the diagnostic tests are run on the devices.
Page 147 IMPORTANT: Run Inspect Computer and have the printed output available before placing a call to the Compaq Customer Support Center or your local Authorized Compaq Service Provider. Running Inspect To run Inspect, complete the following steps: 1.
Page 148: Drive Array Advanced Diagnostics (Daad)
Diagnostics (DAAD) Drive Array Advanced Diagnostics (DAAD) is a DOS-based tool designed to run on all Compaq products that contain a Compaq SMART SCSI Array Controller, Compaq Intelligent Drive Array Controller-2 (IDA-2), Compaq Intelligent Drive Array Controller (IDA), or Compaq Intelligent Array Expansion Controller.
Page 149 Writer: Compaq Computer Corporation Project: Diagnostics Tools Comments: File Name: J-ch8.doc Last Saved On: 4/14/97 12:05 PM...
Page 150 Call your Authorized Compaq Reseller for the Unrecognized status the array accelerator latest copy of DAAD. board that DAAD does not recognize. continued Compaq ProSignia 200 Server Reference Guide Writer: Compaq Computer Corporation Project: Diagnostics Tools Comments: File Name: J-ch8.doc Last Saved On: 4/14/97 12:05 PM...
Page 151 If more than 75% of the batteries are not fully charged, allow 36 hours to recharge them. continued Writer: Compaq Computer Corporation Project: Diagnostics Tools Comments: File Name: J-ch8.doc Last Saved On: 4/14/97 12:05 PM...
Page 152 RAM. that is zero. Old versions of the System Configuration Utility could cause this. continued Compaq ProSignia 200 Server Reference Guide Writer: Compaq Computer Corporation Project: Diagnostics Tools Comments: File Name: J-ch8.doc Last Saved On: 4/14/97 12:05 PM...
Page 153 Call your Authorized Compaq Reseller to obtain needs upgrading however, IDA firmware the latest firmware. (DAAD Error 102) version should be greater than 1.26. continued Writer: Compaq Computer Corporation Project: Diagnostics Tools Comments: File Name: J-ch8.doc Last Saved On: 4/14/97 12:05 PM...
Page 154 Replace the controller as soon as possible. replacing (DAAD Expansion System Error 104) firmware is less than version 1.14. continued Compaq ProSignia 200 Server Reference Guide Writer: Compaq Computer Corporation Project: Diagnostics Tools Comments: File Name: J-ch8.doc Last Saved On: 4/14/97 12:05 PM...
Page 155 Utility to reinitialize the array accelerator board. the Accelerator Disable command. This occurred because of an operating system device driver. continued Writer: Compaq Computer Corporation Project: Diagnostics Tools Comments: File Name: J-ch8.doc Last Saved On: 4/14/97 12:05 PM...
Page 156 Compaq ProSignia 200 Server Reference Guide Writer: Compaq Computer Corporation Project: Diagnostics Tools Comments: File Name: J-ch8.doc Last Saved On: 4/14/97 12:05 PM...
Page 157 If there were multiple errors, this drive may need reading RIS copy DAAD was trying to read to be replaced. from drive (bay) X the RIS from this drive. continued Writer: Compaq Computer Corporation Project: Diagnostics Tools Comments: File Name: J-ch8.doc Last Saved On: 4/14/97 12:05 PM...
Page 158 Compaq ProSignia 200 Server Reference Guide Writer: Compaq Computer Corporation Project: Diagnostics Tools Comments: File Name: J-ch8.doc Last Saved On: 4/14/97 12:05 PM...
Page 159 Replace the array accelerator board and due to cache error due to a catastrophic reconfigure using the System Configuration Utility. cache error. continued Writer: Compaq Computer Corporation Project: Diagnostics Tools Comments: File Name: J-ch8.doc Last Saved On: 4/14/97 12:05 PM...
Page 160 If this does not work, replace CABLE DETECTED the cable. continued Compaq ProSignia 200 Server Reference Guide Writer: Compaq Computer Corporation Project: Diagnostics Tools Comments: File Name: J-ch8.doc Last Saved On: 4/14/97 12:05 PM...
Page 161 The incorrect drive was new drive. Do not run the System Configuration replaced. Utility to reconfigure - you will lose data on the drive. continued Writer: Compaq Computer Corporation Project: Diagnostics Tools Comments: File Name: J-ch8.doc Last Saved On: 4/14/97 12:05 PM...
Page 162 Accelerator Board board has not been System Configuration Utility to configure the configured. board, if desired. continued Compaq ProSignia 200 Server Reference Guide Writer: Compaq Computer Corporation Project: Diagnostics Tools Comments: File Name: J-ch8.doc Last Saved On: 4/14/97 12:05 PM...
Page 163 Replace this drive with a larger capacity drive. insufficient capacity capacity to be used in for its configuration this logical drive configuration. continued Writer: Compaq Computer Corporation Project: Diagnostics Tools Comments: File Name: J-ch8.doc Last Saved On: 4/14/97 12:05 PM...
Page 164 Soft Firmware DAAD has determined Run the Compaq Upgrade Utility to place the Upgrade required that your controller is latest firmware on all drives. running firmware that has been soft upgraded by the Compaq Upgrade Utility.
Page 165 The status of a logical drive may not be WARNING - Drive Drive has its internal Replace the drive with a Compaq supplied drive, Write Cache is write cache enabled. The or restore the drive’s operating parameters. enabled on X drive may be a third- party drive or the drive’s...
Page 166 DAAD and a message indicating the type of adapter last configured in EISA nonvolatile RAM. Compaq ProSignia 200 Server Reference Guide Writer: Compaq Computer Corporation Project: Diagnostics Tools Comments: File Name: J-ch8.doc Last Saved On: 4/14/97 12:05 PM...
Page 167: Appendix A Installing A New Battery
Appendix A Installing A New Battery The ProSignia 200 server has two CMOS memories, one on the system I/O board and the other on the Expansion Options riser board, that require batteries to maintain the contents of the CMOS data.
Page 168: I/O Board Battery Install
The lithium battery may explode if mistreated. The battery is soldered in place and may not be removed. Do not abuse or disassemble. Use only replacement batteries supplied by Compaq Computer Corporation (spare part number 160274-001). 1. Turn off your server, unplug it, and disconnect any external devices.
Page 169: Placing The Battery
Memory Invalid,” you may need to replace the battery providing power to the nonvolatile CMOS on the riser board. Battery life is usually about five to ten years under normal use. Use Compaq replacement battery 160274-001 or a comparable 600-milliampere alkaline, 4.5-volt battery.
Page 170: Riser Board Battery Installation
You can view these parameters by restarting the server and pressing F10 when the square cursor appears in the upper-right corner of the screen. From the Compaq Utilities menu, select Computer Setup. Select Storage, then select Configure Fixed Disk Drive to view the parameters.
Page 171: Battery Placement On Riser Board
When the jumper is placed at E1 / 2-3, the external battery is used. Compaq ProSignia 200 Server Reference Guide Writer: COMPAQ Project: Installing a New Battery Comments: File Name: K-appa.doc Last Saved On: 4/14/97 1:43 PM...
Page 172 4. Replace the server cover. 5. Place the sticker included with your battery kit on the back of your server above the power connector. Writer: COMPAQ Project: Installing a New Battery Comments: File Name: K-appa.doc Last Saved On: 4/14/97 1:43 PM...
Page 173 7. Turn on the server. 8. Run the Compaq System Configuration Utility to reconfigure the system. Refer to Chapter 4, "Using the System Configuration Utility." Compaq ProSignia 200 Server Reference Guide Writer: COMPAQ Project: Installing a New Battery Comments: File Name: K-appa.doc Last Saved On: 4/14/97 1:43 PM...
Page 174: Power Cord Set Requirements
10 A/125 volts AC, or 10A/250 volts AC, as required by each country’s power system. Compaq ProSignia 200 Server Reference Guide Writer: COMPAQ Project: Power Cord Set Requirements Comments: File Name: L-appb.doc Last Saved On: 4/14/97 1:45 PM...
Page 175: Country-Specific Requirements
VCTF, 3-conductor, 1.0 mm conductor size. Wall plug must be a two-pole grounding type with a Japanese Industrial Standard C8303 (7A, 125V) configuration. Writer: COMPAQ Project: Power Cord Set Requirements Comments: File Name: L-appb.doc Last Saved On: 4/14/97 1:45 PM...
Page 176: Appendix C Electrostatic Discharge
Use a portable field service kit with a folding static-dissipating work mat. If you do not have any of the suggested equipment for proper grounding, have an Authorized Compaq Reseller install the part. For more information on static electricity or assistance with product installation, contact your Authorized Compaq Reseller.
Page 177: Appendix D Switches And Jumpers
Setting System Board Switches and Jumpers The Compaq ProSignia 200 system board has one switch module, SW1, that is used to set the processor speed of your server. The system board also includes a jumper block labeled E8 and E6 that control the Power-On-Password and the System Board Configuration Memory.
Page 178: Jumper Settings
Memory becomes corrupt, the switch SW2 on the Riser Card has a maintenance function that can be used to clear corrupt configuration memory. Writer: Compaq Computer Corporation Project: Switches and Jumpers Comments: File Name: N-appd.doc Last Saved On: 4/14/97 1:49 PM...
Page 179: Riser Board Switch And Jumper Settings
Riser Board Switch and Jumper Settings The Compaq ProSignia 200 riser board has one switch module, SW2, which is used to control certain configuration functions of the server. The riser card also contains jumper E1, used to select an external battery for the riser card Configuration Memory.
Page 180: Installing The Server
Be sure you are properly grounded before beginning any installation procedure. Refer to Appendix C, “Electrostatic Discharge,” for more information. Compaq ProSignia 200 Server Reference Guide Writer: Compaq Computer Corporation Project: Installing the Server Comments: File Name: O-appe.doc Last Saved On: 4/14/97 1:51 PM...
Page 181: Overview Of Installing The Server
Installing the Server Overview of Installing the Server Follow this sequence when installing your ProSignia 200 server for the first time. This sequence is the same as illustrated on the Quick Hardware Installation poster that came with your new server. Additional information on each step is provided in the remainder of this manual.
Page 182: Unpacking
Locate the following materials that were shipped with your new server: Documentation and Software Quick Hardware Installation poster Reference Guide SmartStart ProSignia 200 Server Keyboard Compaq ProSignia 200 Server Reference Guide Writer: Compaq Computer Corporation Project: Installing the Server Comments: File Name: O-appe.doc Last Saved On: 4/14/97 1:51 PM...
Page 183: Removing The Side Access Panel
3. Loosen the three thumbscrews on the rear of the unit. 4. Slide the side access panel toward the rear of the unit. See Figure E-1. Writer: Compaq Computer Corporation Project: Installing the Server Comments: File Name: O-appe.doc Last Saved On: 4/14/97 1:51 PM...
Page 184: Replacing The Side Access Panel
If desired, the side access panel can be locked (with a customer-supplied padlock) to prevent unauthorized access to system components. See Figure E-2 for information. Compaq ProSignia 200 Server Reference Guide Writer: Compaq Computer Corporation Project: Installing the Server Comments: File Name: O-appe.doc Last Saved On: 4/14/97 1:51 PM...
Page 185 These panels are an integral part of the cooling system and removing them while the system is running may adversely affect data integrity. Figure E-2. Securing the system with a user-supplied padlock Writer: Compaq Computer Corporation Project: Installing the Server Comments: File Name: O-appe.doc Last Saved On: 4/14/97 1:51 PM...
Page 186: Regulatory Notices
Modifications The FCC requires the user to be notified that any changes or modifications made to this device that are not expressly approved by Compaq Computer Corporation may void the user's authority to operate the equipment. Cables Connections to this device must be made with shielded cables with metallic RFI/EMI connector hoods in order to maintain compliance with FCC Rules and Regulations.
Page 187: Canadian Notice
Equipment Regulations. Avis Canadien Cet appareil numérique de la classe B respecte toutes les exigences du Règlement sur le matériel brouilleur du Canada. Writer: Compaq Computer Corporation Project: Regulatory Notices Comments: File Name: P-appf.doc Last Saved On: 4/14/97 1:53 PM...
Page 188: European Union (Eu) Notice
Japanese Notice Laser Safety All Compaq systems equipped with CD-ROM drives comply with appropriate safety standards including IEC 825. With specific regard to the laser, the equipment complies with laser product performance standards set by government agencies as a Class 1 laser product.
Page 189 Because the internal laser beam may cause eye damage, do not open the cabinet. Wearing glasses and contact lenses, etc., increases the hazard. All maintenance should be performed by an Authorized Compaq Service Provider. WARNING: Use of controls or adjustments or performance of procedures other than those specified herein or in the CD ROM installation guide may result in hazardous radiation exposure.
Page 190: Battery Notices
53.5 Degree +/- 1.5 Degree Output Power: Less than 0.2mW or 10,869 W m Polarization: Circular Numerical Aperture: 0.45 +/- 0.04 Only authorized technicians trained by Compaq should attempt to repair this equipment. troubleshooting repair procedures detailed allow only subassembly/module level repair. Because of the complexity of the individual boards and subassemblies, no one should attempt to make repairs at the component level or to make modifications to any printed wiring board.
Page 191 Batteries, battery packs, and accumulators should not be disposed of together with the general household waste. To forward them for recycling or proper disposal, please use the public collection system or return them to Compaq, your authorized Compaq Partners, or their agents.
Page 192: Index
Utility See ART enabling rapid recovery Automatic Server Recovery-2 services 2-3 See ASR-2 Compaq Utilities starting from remote 2-13 ProSignia 200 Server Reference Guide Writer: Compaq Computer Corporation Project: Index Comments: File Name: Index.doc Last Saved On: 4/14/97 1:58 PM...
Page 193 OS/2 4-16 Error messages Windows NT 4-14 DAAD 8-35 NetWare 4-11 diagnostics 8-22 OS/2 4-16 POST 8-2 Windows NT 4-13 Errors Critical Error Logs 2-4 Writer: Compaq Computer Corporation Project: Index Comments: File Name: Index.doc Last Saved On: 4/14/97 1:58 PM...
Page 194 IP and IPX networks Health Driver 2-14 using ASR-2 2-13 Health Logs, Server 2-4 expansion slots 3-5 installing board 3-7 ProSignia 200 Server Reference Guide Writer: Compaq Computer Corporation Project: Index Comments: File Name: Index.doc Last Saved On: 4/14/97 1:58 PM...
Page 195 Overriding diskette boot control 6-8 adding SIMMs 3-17 cache 1-10 CMOS A-1 Messages Padlock provision 6-11 Critical Error Log 2-5 Parallel DAAD 8-35 and serial interface control 6-9 Writer: Compaq Computer Corporation Project: Index Comments: File Name: Index.doc Last Saved On: 4/14/97 1:58 PM...
Page 196 Removable media storage 3-20 Power cord and peripherals, Removing connecting 3-25 expansion slot cover 3-6 Power supply 1-11 Pentium processor 3-12 ProSignia 200 Server Reference Guide Writer: Compaq Computer Corporation Project: Index Comments: File Name: Index.doc Last Saved On: 4/14/97 1:58 PM...
Page 197 Status indicators for Insight Server Manager 3-4 512-KB secondary cache Storage memory 1-10 installing devices 3-19 Health Logs 2-4 removable media 3-20 maintenance 7-1 Writer: Compaq Computer Corporation Project: Index Comments: File Name: Index.doc Last Saved On: 4/14/97 1:58 PM...
Page 198 Test Warranty 1-11 utility 8-31 Web site, Compaq 1-14 Troubleshooting Windows NT Critical Error Logs 2-4 device drivers 4-13 ProSignia 200 Server Reference Guide Writer: Compaq Computer Corporation Project: Index Comments: File Name: Index.doc Last Saved On: 4/14/97 1:58 PM...
Page 199 ......Index releasing socket 3-13 Writer: Compaq Computer Corporation Project: Index Comments: File Name: Index.doc Last Saved On: 4/14/97 1:58 PM...

Compaq ProSignia 200 Manual

Appendix A Installing a New Battery

Appendix C Electrostatic Discharge

Appendix D Switches and Jumpers

Quick Links

Need help?

Questions and answers

Related Manuals for Compaq ProSignia 200

Summary of Contents for Compaq ProSignia 200

Table of Contents
