NOTE: Unless otherwise directed, the decoder backup file goes to the Downloads
folder of the connected PC.
3. Click Keep to save the file to the Downloads folder or Discard as desired.
RESTORE tab
Restore the decoder settings as follows:
NOTE: Restore is disabled when the decoder is accessed via proxy from the NAVigator.
1. On the Device Tools page, click RESTORE (see figure 31,
2. Click SELECT FILE ( 2
1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1
2 2 2 2 2 2 2 2 2 2 2 2 2 2 2 2 2 2
Figure 31. Device Tools — Restore Function
An Open dialog box opens (see figure 32).
Figure 32. Open Dialog Box
3. Navigate to the folder where the Restore file is saved (typically the Downloads folder)
(see figure 32, 1 ). Select the file.
4. Click Open ( 2 ). The Device Tools page returns to the top (see
NAV 10SD 501 and NAV 10SD 101 Scaling Decoders • HTML Operation
).
1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1
1 ).
2 2 2 2 2 2 2 2 2 2 2 2 2 2 2 2 2 2
figure 33
on page 41).
40
