Performing Mode 4 and 5 Resets
Perform resets of the unit as follows (see figure 9):
1.
Use a small screwdriver to press and hold the rear panel RESET button until the rear
panel Reset LED blinks either:
Two times, for an IP settings reset
•
•
Three times for an absolute (factory) reset
IP Settings
Reset
(Mode 4)
Factory
Reset
(Mode 5)
Figure 9.
2.
Release the RESET button and then immediately press and release the RESET button
again. Nothing happens if you do not momentarily RESET within 1 second.
Press and hold
Reset LED blinks twice.
the Reset button.
6 seconds
RESET
Reset LED blinks
Press and hold
three times.
the Reset button.
9 seconds
RESET
Resets
NAV 10SD 501 and NAV 10SD 101 Scaling Decoders • Installation
Release, then immediately
press and release again.
Release, then immediately
press and release again.
17
