ViewStation H.323 with V.35

The Network Setup screen (System Info > Admin Setup > Video
Network) shown in Figure 2-26 provides four icons which:
• Sets Call Preferences
• Configures Video Network preferences
• Sets video Numbers
• Access the Advanced V.35 Setup features
Figure 2-26. V.35 Network Setup Screen
Call Preference
The Call Preference screen shown in Figure 2-27 determines how
a video call is placed. The two types of video communications for the
ViewStation H.323 with V.35 are:
• V.35 video calls
• LAN/Internet (H.323) video calls
V.35 Video Calls: The V.35 Video Calls option shown in the first
check box in Figure 2-28 determines if V.35 calls are made from
the ViewStation.
• Checked: Enables the V.35 videoconferencing for the
ViewStation H.323 with V.35.
• Not Checked: Disables the V.35 videoconferencing for the
ViewStation H.323 with V.35.
