The Graphic User Interface (GUI) is designed for ease of use. The
following table is a definition of key icon functions:
Icon Name
Text Tab
Select Button
Network Connectivity Error
Call Speed Indicators
Network Line Indicator
Preface — How To Use This Guide
The purpose of the Text Tab is
to enable the user to enter
alphanumeric characters into
the ViewStation. Numbers are
entered with the remote control.
To enter alpha characters press
the SELECT button on the
remote control.
The SELECT button shown is
on the remote control.
The Network Connectivity
Error icon indicates severe
packet loss between the near
end and the far end
ViewStations.
The Call Speed Indicators
illustrate the call speed of the
near end or the far end
ViewStation. Speeds may be set
from the Dialing Speeds
screen. See Dialing Speeds on
page 71.
The Network Line Indicators are
shown when the ViewStation is
powered on.
Yellow Box: Checking line
status
Red Down Arrow: Error in
network link
Green Up Arrow: Line is
connected
