Network Status Indicators

ViewStation User Guide
Figure 1-22. Main Calling Screen
At the top left of the Main Calling screen is the ViewStation type
indicator, which is displayed below the Polycom logo. This indicates
the network interface module (if any) that is configured with the
ViewStation.
Each time the ViewStation is powered on, a set of network status
indicators (network icons) are displayed below the Video Call icon
on the Main Calling screen. The Network icon flashes a yellow
numbered box while the ViewStation is validating each network line
or is waiting for the DHCP server (if used) to assign it an IP address.
If the ViewStation uses a static or fixed IP address, the ViewStation
verifies the IP is not in use.
Icon
Green Up Arrow
Meaning
Network line is connected.
The ViewStation is ready to place a video call.
