Polycom ViewStation EX User Manual page 212

Appendix C
State
9 DPR = 0
10 If not the last digit go to state 4; otherwise
continue.
11
12
13 RTS = 1<note 2>
14 DATA FLOW STARTS
User Hang-up
15 RTS = 0 <note 2>
DTR = 0 <note 3>
CRQ = 0
All signals go low if Far End or User hang-up is
detected.
IDLE
DTR = 0 <note 3>
RTS = 0 <note 2>
CRQ = 0
ViewStation User Guide
ViewStation Signals
Note 1: DSR is used as a ring-in indicate if DSR is set to ANSWER
in the V.35 Advanced Configuration screen.
Note 2: RTS does not act as shown but act as a resync-pulse if
Security/Crypto-Resync is set to ON.
Note 3: DTR does not act as shown but remains at a high voltage is
DTR is set to ON in the V.35 Advanced Configuration screen.
Network Equipment Signals
Call connects on network
DSR = 1 AND/OR DCD = 1
(AND/OR DSR = 1 <note 1>)
DATA FLOW STARTS
Far End Hang-up
DSR= 1 to 0, OR DCD= 1 to 0
A falling edge on DSR or DCD is interpreted by
the VS4000 as a hang-up.
IDLE
RI = 0
DLO = 0
ACR = 0
DSR = 0
196
V.35 Technical Information
www.polycom.com
