Video and Audio Input and Output Levels

Video Levels

This information applies to all Polycom videoconferencing products.

Video Output Levels

Video Input Levels

Audio Levels

Audio Output Levels

© 2001 Polycom Inc.
Composite and S-video outputs:
• 75 ohm output typical
• NTSC or PAL video standard waveform
• 1.0 Vpp typical per NTSC/PAL standard
• All video outputs are DC coupled
Composite and S-video inputs:
• 75 ohm input termination
• NTSC or PAL video standard waveform
• 1.0 Vpp typical per NTSC/PAL standard expected input
• All video outputs are DC coupled
RCA audio output connectors:
• 800 ohm maximum output impedance
• 1.0 Vpp full scale output typical
• All audio outputs are AC coupled
191
B
ViewStation User Guide
