Drop Installation - Chore-Time ATF Installation And Operator's Manual

MODEL ATF™ and MODEL ATF™ PLUS Feeding System

Drop Installation

1
3
7
Attaching Ceiling Hooks
Throwback Cable Arrangement
Cable included for Throwback pulleys beneath or near Winch (See Figure 16.)
3
2
MF2505A
5
4
2
8
Figure 15.Standard Drop arrangement
1
3
4
5
6
Figure 16.Drop Installation Throwback arrangement
3
6
Item
1 Pulley
2 3/32" [2.4 mm] or 1/8" [3.18 mm] Cable
3 Pull Direction (Toward Winch)
4 3/16" Cable Clamp
5 6" [150 mm]
6 Cable Lock (Adjustment Leveler) See
Figure 28. on page 24.
7 1/4-20 Lag bolt
8 Ceiling Hook
3
Item
1 Pulley
2 3/32" [2.4 mm] or 1/8" [3.18 mm] Cable
3 Pull Direction (Toward Winch)
4 3/16" Cable Clamp
5 6" [150 mm]
6 Cable Lock (Adjustment Leveler) See
Figure 28. on page 24.
Description
Description
Installation
Part No.
3004
--
--
732
--
14337
--
28550
Part No.
3004
--
--
732
--
14337
19
