Electrical and Mechanical Specifications
Specification
Output Current Rating @ 40°C ambient
Nominal Battery System Voltage
PV open circuit voltage
Standby power consumption
Charge cycle
Voltage regulation set points
Temperature compensation
PV input capability
Digital Display
Remote Interface
Operating Temperature Range*
Conduit knockouts
Warranty
Dimensions
Shipping Dimensions
Weight
Options
Menu Languages
Firmware Revision
This manual applies to FLEXmax 80 or FLEXmax 60 charge controllers with a firmware revision of
002.001.xxx or higher.
Regulatory Specifications
Table 3
UL 1741 1st Edition; 2005 Version, CSA 107.1-01
CE Conformance European EN 55022 Class B
C
900-0009-01-00 Rev
FLEXmax 60
60 amps continuous
12, 24, 36, 48 or 60 Vdc (adjustable)
150 Vdc maximum (ETL Rating for UL1741 Standard);
145 Vdc temperature corrected Voc (operational maximum)
Less than 1 watt typical
Three-stage
13-80 Vdc
5 mV per °C per 2 V cell (with optional RTS)
Down convert from any acceptable array voltage to any battery voltage.
Examples: 72 Vdc array to 24 Vdc battery; 60 Vdc array to 48 Vdc battery
4-line, 20-character per line backlit LCD display
RJ45 modular connector Cat 5 cable 8 wire
-40° to 60°C (automaticaly derated above 40°C)
One 1" on the back; one 1" on the left side; two 1" on the bottom
Five years parts and labor
13.5" H x 5.75" W x 4" D
18" H x 11" W x 8" D
11.6 lb (14 lb boxed)
RTS, HUB 4, HUB 10, MATE, MATE2, MATE3
English and Spanish
Regulatory Specifications for All Models
Specifications
FLEXmax 80
80 amps continuous
16.25" H x 5.75" W x 4"D
21" H x 10.5" W x 9.75"D
12.20 lb (15.75 lb boxed)
93
