End-Of-Day Summary Screen - Alpha Group OutBack Power FLEXmax Series Owner's Manual

Operation

End-of-Day Summary Screen

The end-of-day summary screen appears after one hour of continuous Sleeping (see page 23). This
screen can be opened any time by pressing the second soft key while in the status screen, providing a
summary up to that point.
NOTE:
When finished viewing the
end-of-day screen(s), be sure to
return the display to the status
screen. Otherwise, it will not reset
the counters when the sun rises the
next morning. The values will
continue to accumulate.
18
End-of-Day Screen
Today 000Ah
011Vp 00.0Ap 0.00kWp
MAX 14.7 V
MIN 14.6 V
Today 000Ah
011Vp 00.0Ap 0.00kWp
MAX 14.7 V
MIN 14.6 V
Today 000Ah
011Vp 00.0Ap 0.00kWp
MAX 14.7 V
MIN 14.6 V
Today 000Ah
011Vp 00.0Ap 0.00kWp
MAX 14.7 V
MIN 14.6 V
Today 000Ah
011Vp 00.0Ap
MAX 14.7 V
MIN 14.6 V
Today 000Ah
011Vp 00.0Ap
MAX 14.7 V
MIN 14.6 V
Today 000Ah
011Vp 00.0Ap 0.00kWp
MAX 14.7 V
MIN 14.6 V
Today 000Ah
011Vp 00.0Ap 0.00kWp
MAX 14.7 V
MIN 14.6 V
Today 000Ah
011Vp 00.0Ap 0.00kWp
MAX 14.7 V
MIN 14.6 V
Today 000Ah
011Vp 00.0Ap 0.00kWp
MAX 14.7 V
MIN 14.6 V
Figure 12 End-of-Day Summary Screen
00.0kWH
Day (up to 128 days)
ABS 01:00
FLT 00:00
00.0kWH
Accumulated
ABS 01:00
Amp-hours
FLT 00:00
00.0kWH
Accumulated kWh
ABS 01:00 Total Power
FLT 00:00
00.0kWH
Peak Input Voltage
ABS 01:00
FLT 00:00
00.0kWH
0.00kWp
Peak Output Current
ABS 01:00
FLT 00:00
00.0kWH
Peak Output Power
0.00kWp
ABS 01:00 in Kilowatts
FLT 00:00
00.0kWH
Maximum Battery
ABS 01:00
Voltage Obtained
FLT 00:00
00.0kWH
Accumulated
ABS 01:00 Absorb Time
FLT 00:00
00.0kWH
Minimum Battery
ABS 01:00
Voltage Obtained
FLT 00:00
00.0kWH
Accumulated
ABS 01:00
Float Time
FLT 00:00
