The MATE3 provides the means for programming the FLEXmax charge controller and other devices
when preprogrammed default settings do not work for the destined installation.

Display and LED Status Indicators

Inverter LED
Charger LED
Generator LED
Figure 54
C
900-0009-01-00 Rev
MATE3 System Display and
Battery Status LEDs (x3)
Display and LED Status Indicators
Controller
LCD Screen
Events LED
AC Input LED
Favorite LED
