Starting with revision 3 modules, access to the SD card is conditioned by the state of EMMC_EN# signal
(eMMC flash enable).
Please note that external pull-ups are needed for SD card operation. Depending on the selected voltage
for VCC_CFG_HPS_B3A_B8A, a level shifter to 3.3 V may be required (some level shifters also have built-in
pull-ups).
2.17.1

Signal Description

HPS Pin
36
38
39
45
46
47
Table 23: SD Card Signals
2.18

eMMC Flash

Starting with revision 3, an eMMC flash is equipped on the module. This can be used to boot the HPS, and
to store the FPGA bitstream, ARM application code and other user data.
2.18.1

eMMC Flash Type

Table 24 describes the memory availability and configuration on the Mercury SA1 SoC module.
Flash Type
H26M52208FPRI
EMMC16G-W525-X01U
EMMC16G-IB29-PZ90
Table 24: eMMC Flash Type
Warning!
Other flash memory devices may be equipped in future revisions of the Mercury SA1 SoC module.
Please check the user manual regularly for updates. Any parts with different speeds and temperature
ranges that fulfill the requirements for the module variant may be used.
D-0000-402-002
SD Card Signal
CMD
D0
D1
CLK
D2
D3
Size
16 GB
16 GB
16 GB
31 / 49
Connector Pin
A-93
A-95
A-97
A-91
A-101
A-103
Manufacturer
SK Hynix
Kingston
Kingston
Version 06, 16.02.2021
