Multi-Gigabit Transceiver (Mgt); Hps Pin Connections - Enclustra Mercury SA1 SoC Module User Manual

HPS_GPIO Function
40 Boot mode 0
41 Gigabit Ethernet link status (ETH_LED2#, input,
active-low)
42 Boot mode 1
43 Power good (input, active-high)
44 Gigabit Ethernet PHY reset (output, active-low)
48-51 LEDs (shared with FPGA I/Os)
53 eMMC enable signal (output, active-low)
54-56 I2C
57-60 SPI/user functionality
61-62 CAN/user functionality
63 UART1 RX
64 UART1 TX
65 UART0 RX
66 UART0 TX
Table 9: HPS Pin Connections
3
2.10

Multi-Gigabit Transceiver (MGT)

There are six Multi-Gigabit transceivers and two reference input clock differential pairs on the Mercury SA1
SoC module routed directly to the module connector B.
The transceivers on the SoC device support a data rate of 3.125 Gbit/sec.
Warning!
The maximum data rate on the MGT lines on the Mercury SA1 SoC module depends on the routing
path for these signals. Adequate signal integrity over the full signal path must be ensured when using
MGTs at high performance rates.
2
eMMC flash interface is available starting with revision 3.
3
UART RX is an SoC input; UART TX is an SoC output.
D-0000-402-002
3
/user functionality
3
/user functionality
3
/user functionality
3
/user functionality
22 / 49
Connection
BOOT_MODE0
Gigabit Ethernet PHY
BOOT_MODE1
PWR_GOOD
Gigabit Ethernet PHY
On-board LEDs
2
SDIO clock multiplexer
On-board I2C bus and module
connector via level shifter
Module connector
Module connector
Module connector
Module connector
Version 06, 16.02.2021
