Product Information; Module Configuration; Soc Device Types - Enclustra Mercury SA1 SoC Module User Manual

Module
Mercury SA1 SoC module
Table 36: Product Information

Module Configuration

Addr. Bits Comment
7-4 SoC Type
0x08
3-0 SoC device speed grade
7 Temperature range
6 Power grade
5-4 Ethernet port count
0x09
3 Ethernet speed
2 RTC equipped
1-0 Reserved
7-2 Reserved
0x0A
1-0 USB 2.0 port count
7-4 DDR3L RAM size (MB)
0x0B
3-0 QSPI flash memory size (MB)
7-4 Reserved
0x0C
3-0 eMMC flash size (GB)
Table 37: Module Configuration
The memory sizes are defined as Resolution 2
DRAM=2: 16 MB, DRAM=3: 32 MB, etc).
Table 38 shows the available SoC types.
Value SoC Device Type
0 5CSEBA2U23
1 5CSXFC5C6U23
2 5CSXFC6C6U23
Table 38: SoC Device Types
6
Property introduced starting with revision 3 modules, which are equipped with an eMMC flash. For older revisions, a value of 0
is programmed to the EEPROM.
D-0000-402-002
Product Family Reserved
0x0326 0x[XX]
Min. Value
0
6
0 (Commercial)
0 (Normal)
0
0 (Fast
Ethernet)
0
-
-
0
0 (0 MB)
0 (0 MB)
-
6
0 (0 GB)
(Value-1)
(e.g. DRAM=0: not equipped, DRAM=1: 8 MB,
43 / 49
Revision

Product Information

0x[YY] 0x0326 [XX][YY]
Max. Value Comment
2 See SoC type table
(Table 38)
8
1 (Industrial)
1 (Low Power)
1
1 (Gigabit
Ethernet)
1
-
-
1
10 (4 GB) Resolution = 8 MB
7 (64 MB) Resolution = 1 MB
-
5 (16 GB) Resolution = 1 GB
Version 06, 16.02.2021
