Mechanical Data; Module Connector; Module Connector Types - Enclustra Mercury SA1 SoC Module User Manual

2.7

Mechanical Data

Table 3 describes the mechanical characteristics of the Mercury SA1 SoC module. A 3D model (PDF) and a
STEP 3D model are available [8], [9].
Symbol
Size
Component height top
Component height bottom
Weight
Table 3: Mechanical Data
2.8

Module Connector

Two Hirose FX10 168-pin 0.5 mm pitch headers with a total of 336 pins have to be integrated on the base
board. Up to four M3 screws may be used to mechanically fasten the module to the base board. Do not
use excessive force to tighten the screws, as this could damage the module.
The pinout of the module connector is found in the Mercury Master Pinout Excel Sheet [11]. The connector
is available in different packaging options and different stacking heights. Some examples are presented in
Table 4. Please refer to the connector datasheet for more information.
Reference
Mercury module connector
Base board connector
Base board connector
Table 4: Module Connector Types
Figure 9 indicates the pin numbering for the Mercury module connectors from the top view of the base
board. The connector pins are numbered as follows:
Connector A: from J700-1 to J700-168
Connector B: from J701-1 to J701-168
D-0000-402-002
Value
56 54 mm
5.0 mm
1.35 mm
20 g
Type
FX10A-168S-SV
FX10A-168P-SV(71)
FX10A-168P-SV1(71)
15 / 49
Description
Hirose FX10, 168-pin, 0.5 mm pitch
Hirose FX10, 168-pin, 0.5 mm pitch, 4 mm stacking
height
Hirose FX10, 168-pin, 0.5 mm pitch, 5 mm stacking
height
Version 06, 16.02.2021
