Warning!
It is possible to mount the Mercury SA1 SoC module the wrong way round on the base board - always
check that the mounting holes on the base board are aligned with the mounting holes of the Mercury
SA1 SoC module.
The base board and module may be damaged if the module is mounted the wrong way round and
powered up.
1.1.6

Electrostatic Discharge

Electronic boards are sensitive to electrostatic discharge (ESD). Please ensure that the product is handled
with care and only in an ESD-protected environment.
1.1.7

Electromagnetic Compatibility

The Mercury SA1 SoC module is a Class A product (as defined in IEC 61000-3-2 standard) and is not in-
tended for use in domestic environments. The product may cause electromagnetic interference, for which
appropriate measures must be taken.
1.2

Features

Altera Cyclone V SOC 5CSXFC6C6U23C8N/5CSXFC6C6U23I7N
ARM dual-core Cortex A9
Altera Cyclone V 28 nm FPGA fabric
178 user I/Os up to 3.3 V
16 ARM peripheral I/Os (SPI, SDIO, CAN, I2C, UART)
134 FPGA I/Os (single-ended or differential)
28 MGT signals (clock and data)
6 MGTs @ 3.125 Gbit/sec and 2 reference input clock differential pairs
PCIe Gen1 4 (Altera PCIe hardened IP block)
1 GB DDR3L SDRAM
64 MB quad SPI flash
16 GB eMMC flash (starting with revision 3)
Gigabit Ethernet
USB 2.0 On-The-Go (OTG)
CAN, UART, SPI, I2C, SDIO/MMC
Real-time clock
Small form factor (56
5 to 15 V supply voltage
1.3

Deliverables

Mercury SA1 SoC module
Mercury SA1 SoC module documentation, available via download:
Mercury SA1 SoC Module User Manual (this document)
Mercury SA1 SoC Module Reference Design [2]
Mercury SA1 SoC Module IO Net Length Excel Sheet [3]
Mercury SA1 SoC Module FPGA Pinout Excel Sheet [4]
Mercury SA1 SoC Module User Schematics (PDF) [5]
Mercury SA1 SoC Module Known Issues and Changes [6]
Mercury SA1 SoC Module Footprint (Altium, Eagle, Orcad and PADS) [7]
D-0000-402-002
54 mm)
