FPM PROFINET
LED
Power
COM
Link (XF 1 and XF 2)
Rx/Tx (XF 1 and XF 2)
Tab. 4.3:
Light signals and colors PROFINET
4.5
Scope of delivery and optional accessories
The scope of delivery includes:
•
FPM
•
USB flash drive
•
Operating manual (printed version)
The following accessories are optional:
•
Transport and storage case
•
Maintenance hatch with passage for Ethernet
14
M12
®
Color
State
Meaning
Green
On
Supply voltage applied.
Watchdog timeout or „Channel, generic or extended diagnostics
Green
On
present" or system error.
Grün
Blinks
DCP signal service is triggered via the bus.
Red
On
No configuration or slow physical connection or no physical connection.
Red
Blinks
No data exchange.
Green
On
The device has a connection to the Ethernet.
Gelb
Flickers
The device sends/receives Ethernet frames.
M12
®
FocusParameterMonitor FPM
Revision 06 EN 02/2023
