Install the Access Point

Installation Do's and Don'ts
Access Point Bracket Usage and Mounting Options
Install the Access Point on a Wall
Install the Access Point on a Pole
Install the Plastic Service Panel on the Access Point
Secure the Access Point after Installation
Power or Pressure Washing Guidelines
About This Task
The AP5050D access point can be installed on a wall or to a pole. The
Information
installation needs.
Note
The access point ships with two black gaskets in the box for use with Category 6 (CAT
6) Ethernet cables with a cable diameter from 6.0mm to 9.2mm. This includes unshielded
twisted-pair (UTP) Cat 6 cables. Store these gaskets in a safe place if you do not use them
right away.
The access point has light-gray gaskets pre-installed in the access point glands. The light-gray
gasket handles all CAT 5 and CAT 5E cables, with a cable diameter range from 4.5mm to
6.0mm.
Procedure
1. Review the
2. Visually inspect the access point and any other bracket and optional accessories you have ordered
for physical damage.
If there is any damage, contact
3. Review the
4. Be familiar with the information in the installation guide, in particular the
16 ExtremeWireless™ 802.11ax Wi-Fi 6E Outdoor AP5050D Access Point
on page 17
on page 20
on page 29
on page 13 gives you more details about choosing the right access point bracket for your
purchase order information.
Extreme Networks
safety guidelines.
on page 19
on page 39
on page 41
on page 42
AP5050D Purchase Order
Support.
installation do's and don'ts.
