AP5050D Features
For LED activity description, see
•
3 mm diameter safety hanger provision
•
Power: PoE 802.3at and 802.3bt: PSE enabled with 4x4x4
•
For complete power profile information, refer to the AP5050U
•
Antenna:
◦ Two software selectable internal antennas (30 degree and 70 degree directional antennas)
•
Temperature:
◦ -40°C to +60°C (-40°F to +140°F) operating temperature
◦ -40 °C to +70 °C (-40 °F to +158 °F) storage temperature
•
Enclosure: Plastic top enclosure and aluminum bottom
•
One micro USB console port for troubleshooting or debugging issues
You can order a micro USB console adapter for your access point using the part number ACC-WIFI-
MICRO-USB.
Consult the following illustration for information on the AP5050D side ports. For more information, see
the Universal Wireless AP5050U and AP5050D data
Figure 1: AP5050D Side Ports
Table 4: AP5050D Side Ports Descriptions
Callout Description
1 Eth1 is 2.5/1GE/100 with PoE power sourcing equipment (PSE) 15.4W when
802.3bt on Eth0
2 Eth0 is 5/2.5/1GE with Power over Ethernet (PoE)
3 Console port for troubleshooting
10 ExtremeWireless™ 802.11ax Wi-Fi 6E Outdoor AP5050D Access Point
AP5050D Status LED Activity Description
sheet.
AP5050D Overview
on page 12.
power profile.
