KT-147407-02 Bracket Order Information
•
MBO-ART02 (20 degree increments +/-80 degree, 10 inch extension) with the WS-MBO-POLE01
(#30520) bracket
Note
You can attach the access point to a wall using the MBO-ART02 bracket. However, if you
are using the MBO-ART02 bracket to attach the access point to a pole, you must use the
WS-MBO-POLE01 bracket along with the MBO-ART02 bracket.
Note
You cannot attach the access point directly to a pole using the WS-MBO-POLE01 bracket.
The ordering details are described in the following table.
Table 9: KT-147407-02 Purchase Information
Part number Box contents
KT-147407-02 The KT-147407-02 bracket comes with three bracket parts:
• Flat part with holes on the metal surface
• 1-axis tilt part
• Boxed pole part with step edges
Six hex-head M6 stainless-steel screws
Two hex-head M12 stainless-steel screws
Two hex M12 stainless-steel nuts
One URL card
The KT-147407-02 bracket kit can be used with KT-150173-01 extension arm for adding +/15 degree tilt
to wall or pole installations.
Note
You must purchase the KT-150173-01 extension arm separately.
