Install the Access Point

Install the Access Point on a Pole

Before You Begin
The access point is used with the KT-147407-02 bracket parts and KT-150173-01 extension arm for pole
installation. The access point is mounted on a pole by attaching:
1. All three parts of the KT-147407-02 bracket.
2. The KT-150173-01 extension arm with all the KT-147407-02 bracket parts.
3. The pole bracket part of the KT-147407-02 bracket.
4. The KT-150173-01 extension arm with the pole part of the KT-147407-02 bracket.
The following hardware is required to install the access point on a pole:
•
Flat part of the KT-147407-02 bracket
•
Pole part of the KT-147407-02 bracket
•
1-axis tilt bracket
•
Six M6 screws
•
Two hex-head M12 stainless-steel screws
•
Two hex-heads M12 stainless-steel nuts
•
Two M12 screws
•
Two M12 hex nuts
•
0.5 in. wide stainless-steel cable clamps
•
KT-150173-01 extension arm
Note
You must provide M6 hex-head screws and screw-in anchors.
Note
The cable glands must face down when you install the access point on a pole.

Install the Access Point on a Unistrut Structure Using the MBO-ART03 Bracket

Before You Begin
The following hardware is required to install the MBO-ART03 bracket on a Unistrut structure:
•
One MBO-ART03 bracket
The MBO-ART03 bracket ships with the following hardware:
◦ Two long screws
◦ Four short screws
◦ Four nuts
Note
For Unistrut installations, discard two of the short screws and nuts. Provide two M12
stainless steel bolts, hex nuts, and split washers.
