Install the Access Point on a Unistrut Structure Using
the MBO-ART03 Bracket
About This Task
The MBO-ART03 bracket is a Unistrut mounting bracket with +/- 80-degree (in 10-degree increments)
2-axis tilt and variable 7 inches to 10 inches extension. The bracket comes installed with M6 pivot
screws.
On the MBO-ART03 bracket's flat surface, there are three large holes for interfacing with the Unistrut
metal frame. Each metal bracket on either end of the ART03 bracket has two bent sections with two
pivot holes and serrated lock positions.
The length on the bent sections can be adjusted, if desired. Move the pivot points to increase the
MBO-ART03 bracket's extension lengths to 7.5 in., 9.0 in., or 10.5 in.
Adjust the MBO-ART03 bracket's extension:
1. Remove the pivot screw and nut.
2. Move the MBO-ART03 bracket arm's center hole to the other pivot hole on the bracket.
3. Insert the pivot screw through the bracket and the arm.
4. Attach the pivot nut to the screw.
Use a crescent wrench or a 13 mm tool to tighten the pivot screws and nuts.
5. Torque the screws and nuts to finger tightness.
Adjust the MBO-ART03 bracket's angular position
1. The horizontal and vertical adjustments can be made in 10 degree increments.
The increments are marked on the MBO-ART03 bracket.
2. Rotate the arm to the desired position.
3. When the lock screw hole lines up with the appropriate serrated screw hole, insert the long M6
screw and fasten with a hex nut.
The left to right adjustment can be made to any angle, with the access point having at least 1 in.
clearance from another object.
30 ExtremeWireless™ 802.11ax Wi-Fi 6E Outdoor AP5050D Access Point
Note
The access point glands must point downward to prevent water entry.
Note
The vertical adjustment must be less than or equal to 25 degrees to prevent water entry
into the AP560iAP560i, AP560hAP560h, and AP560uAP560u model access points.
Tip
The best practice is to make the vertical adjustment before attaching the access point to
the MBO-ART03 bracket.
