Secure The Access Point After Installation - Extreme Networks ExtremeWireless AP5050D Installation Manual

Install the Access Point
3. Place the service panel top over the service panel base and lock it into place using the captive screw.
Figure 15: Plastic service panel top captive screw
Callout
1
4. Torque the screws to 4 1/2 in-lbs.

Secure the Access Point after Installation

Details about installing a security cable on the access point after installation.
Before You Begin
The following hardware must be supplied by the user for safety cable installation:
•
A 3 mm diameter security cable
•
Lock to secure the ends of the security cable
About This Task
You can secure the access point to the mounting environment using a 3 mm diameter safety cable. The
safety cable is used to enhance the physical security of the access point after installation.
Procedure
1. Insert the safety cable through the security cable hole on the metal base of the access point.
Figure 16: Security cable hole on the access point
2. Push the cable through the security hole until you see it come out on the other side of the metal
base.
3. Insert a lock through the looped ends of the cable and lock it in place.
Description
Plastic service panel top captive screw
ExtremeWireless™ 802.11ax Wi-Fi 6E Outdoor AP5050D Access Point
Secure the Access Point after Installation
41
