Install the Access Point

Install the Access Point on a Wall Using MBO-ART02 Articulating Mounting Bracket

Before You Begin
Obtain the items listed in the following table.
Table 15: Hardware Requirements for MBO-ART02 Articulating Mounting Bracket Wall Installation
Quantity Item
1 Access point
1 MBO-ART02 articulating mounting bracket
6 M6 hex-head screws
Two M6 hex-head screws to attach the MBO-ART02 to the access point.
Four M6 hex-head screws to attach the MBO-ART02 bracket to the wall.
Note
When using the MBO-ART02 articulating mounting bracket, set the minimum downward tilt
to less than 20 degrees to prevent water ingress.
Install the Access Point on a Wall Using MBO-ART02
ExtremeWireless™ 802.11ax Wi-Fi 6E Outdoor AP5050D Access Point
Articulating Mounting Bracket
