AP-7562 Access Point

Installation Guide

Published June 2017
9035104
9035104
Published June 2017
9035104

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the AP-7562 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Extreme Networks AP-7562

Summary of Contents for Extreme Networks AP-7562

  • Page 1: Installation Guide

    AP-7562 Access Point Installation Guide Published June 2017 9035104 9035104 Published June 2017 9035104...

  • Page 2: Legal Notices

    Copyright © 2017 Extreme Networks, Inc. All Rights Reserved. Legal Notices Extreme Networks, Inc. reserves the right to make changes in specifications and other information contained in this document and its website without prior notice. The reader should in all cases consult representatives of Extreme Networks to determine whether any such changes have been made.

  • Page 3: Table Of Contents

    Contents Contents Introduction .......................3 AP-7562 Access Point Overview ..........................3 AP-7562 Hardware ................................4 Antenna Accessories ............................... 4 Dual Band 2.4 GHz / 5 GHz Antenna - US and Canada ....................5 Single Band 2.4 GHz Antennas - US and Canada ......................5 Single Band 5 GHz Antenna - US and Canada .........................
  • Page 4 CE Marking and European Economic Area (EEA) ....................47 Statement of Compliance ............................48 Other Countries ................................48 Waste Electrical and Electronic Equipment (WEEE) ..................50 TURKISH WEEE Statement of Compliance ......................51 End-User Software License Agreement...............53 AP-7562 Series ROHS Compliance..............59 AP-7562 Installation Guide...

  • Page 5: Introduction

    The AP-7562 is a 3x3:3 802.11ac Access Point utilizing one 2.4 GHz 802.11n radio and one 5 GHz 802.11ac radio. The AP-7562 is optimized with WiNG intelligence, extending QoS, security, and mobility services to the Access Point to support better capacity and performance.

  • Page 6: Ap-7562 Hardware

    See the antenna guide for specific antenna patterns. Antenna Accessories NOTE AP-7562 Access Points ship with one weatherized Ethernet adapter (except M12 connector models). AP-7562 Access Points do not ship with the Mounting Kit/ Antenna and POE injector. These items must be ordered separately. AP-7562 Installation Guide...

  • Page 7: Dual Band 2.4 Ghz / 5 Ghz Antenna - Us And Canada

    Per FCC requirement, the use of the Access Point on UNII-1 band requires installers to input antenna elevation gain for dipole antennas during configuration. This information can be found in the Extreme Networks Antenna Specification Guide available at http:// documentation.extremenetworks.com.

  • Page 8: Dual Band 2.4 Ghz / 5 Ghz Antennas - Emea

    Dipole AP-7562-670042-US 5.4* NOTE *The elevation gain for the AP-7562-670042-US version SKU is built into the WiNG software, the professional installer does need to manually enter it. Dual Band 2.4 GHz / 5 GHz Antennas - EMEA Antenna 2.4 GHz 5.2 GHz...

  • Page 9: Hardware And Mounting Accessories

    Introduction Hardware and Mounting Accessories The AP-7562 is a Power over Ethernet (PoE) device. When deployed, the use of an outdoor rated PoE power supply and mounting bracket may be required. The recommended PoE accessories are listed in the following table:...
  • Page 10 Introduction The AP-7562-6704M is an M12 version of the AP-7562 ruggedized IP 67 Access Point specifically designed for harsh environments requiring locking connectors for industrial applications. M12 connectors provide a reliable sturdy connection when subjected to shock and vibration. GE Ports - M12 8-Pole X-Coded Female Console Port - M12 4-Pole A-Coded Female GE ports support the use of commercially available M12 X-Coded Ethernet cables.

  • Page 11: Package Contents

    Pin 4 - Ground Package Contents Carefully remove all protective packing material around the AP-7562 Access Point and save the container for storage. Refer to <bl_blue><em_Emphasis>Hardware and Mounting Accessories on page 7 when verifying all AP-7562 hardware has been received.

  • Page 12: Precautions

    Access Point and mounting asset are properly grounded. The grounding cable for an AP-7562 must be at a minimum a #10 gauge wire cross section. The cable can be attached to the unit using one of the following methods: •...

  • Page 13: Access Point Placement

    Access Point from the bottom, and include a drip loop to prevent moisture intrusion. Access Point Placement Observe the following recommended guidelines: Identify each piece of the mounting bracket and mounting extension arm hardware and ancillary hardware. AP-7562 Installation Guide...

  • Page 14: Hardware Overview

    Line of Sight (LoS) guidelines should be given special consideration when deploying devices. Hardware Overview The AP-7562 is a 3x3:3 802.11ac Access Point utilizing one 2.4 GHz 802.11n radio and one 5 GHz 802.11ac radio. An AP-7562 must be installed by trained professionals familiar with RF planning and regulatory limits defined by the regulatory bodies of the country where the devices are being deployed.

  • Page 15: Antenna Mounting Guidelines

    Introduction AP-7562 Access Points (AP-7562-67040-US and AP-7562-67040-1-WR) are configured with six N type connectors to support two active WLAN data radios. WARNING Antenna ports where no antenna is mounted must be properly terminated using an approved IP67 terminator. WARNING All antenna connectors should be covered with weatherproofing tape.

  • Page 16: Grounding Post

    The following are examples of acceptable mounting methods for panel antenna deployments: For the units utilizing an antenna façade, the unit can be mounted on a pole or in the ceiling as long as the unit faces its intended radio coverage area. Grounding Post AP-7562 Installation Guide...

  • Page 17: Vmm Mounting And Installation

    5 architecture that uses the same hardware as the AP-7562 Access Point infrastructure models. An AP-7562 Access Point operating as a VMM can be permanently mounted in a vehicle. It provides mesh backhaul access to a mesh infrastructure network to connect mobile data terminals, laptop computers, or any other device with either Ethernet or 802.11 wireless...
  • Page 18 (KT-158767-01) for mobile deployments. To install the Access Point VMM: 1 Remove the rubber plugs from the four screw holes on the LED side of the AP-7562. Position unit with screw holes facing upwards.
  • Page 19 3 Put the chassis mount on the flat plate with the key hole and four screw holes aligned. NOTE The screw heads on the chassis mount should be facing down. 4 Put the stiffener plate on the chassis mount with the key hole and four screw holes aligned. AP-7562 Installation Guide...
  • Page 20 9 Attach the vehicle mount securely to the mount point with metal screws or bolts (not provided). 10 Securely attach the AP-7562 top bracket sub-assembly to the vehicle mount with the four pre-installed thumb screws. Tighten the screws to 90 inch pounds (lbf-in) using a philips screwdriver or pliers.

  • Page 21: Vmm Power Options

    Introduction VMM Power Options A mounted AP-7562 operating as a VMM within a vehicle or mobile asset requires a power source delivered via Power over Ethernet (PoE). A professional certified installation partner should be consulted in respect to appropriate power sources and installation within a vehicle or mobile asset.

  • Page 22: Led Indicators

    Introduction LED Indicators AP-7562 Access Points have LED activity indicators on the front of the enclosure. The LEDs provide a status display indicating error conditions, transmission, and network activity for the 2.4 GHz radio (green) and the 5 GHz radio (amber).

  • Page 23: Hardware Mounting And Installation

    Mounting Bracket Kit The AP-7562 mounting bracket kit (KT-147407-01) includes the Access Point bracket (left), angle adapter bracket (center), and pole mount bracket (right) sections: The Access Point bracket and angle adapter bracket can be rotated (plus or minus 15 degrees) and tilted (up to 45 degrees) to orient the unit for optimal positioning.
  • Page 24 Hardware Mounting and Installation When mounting an AP-7562 on poles more than 3 inches in diameter, use the extension arm kit (KT-150173-01) to provide a minimum standoff distance of twelve inches to avoid interference with the antennas. The extension arm kit can also be used in combination with the any of the brackets from the mounting bracket kit.

  • Page 25: Pole Mounted Installations

    The mounting hardware kit and extension arm can be used in various combinations to properly install the AP-7562 on a pole. For poles up to 3 inches in diameter, attach the pole mount bracket of the mounting hardware kit at the desired position on the pole using band clamps up to 3/4 inch width, or a 1/2 inch x 4 inch wide U-bolt and nuts.

  • Page 26: Vertical Pole Mount

    3 Place the angle adapter bracket on the U-bolt with the open slot connections on the bottom and align it with the pole mount. Attach with two 1/2 inch nuts. Tighten all nuts to 300 inch pounds (lbf-in). AP-7562 Installation Guide...
  • Page 27 AP with the gore vent. Attach (but don’t tighten) the bracket to the AP-7562 with the four M6 flange screw using a torque wrench, a ratchet and a 10mm socket or an adjustable wrench.
  • Page 28 Hardware Mounting and Installation 5 Insert two M6 hex flange screws into the bottom holes on the sides of the Access Point bracket. AP-7562 Installation Guide...
  • Page 29 6 With the Access Point positioned so the gore vent is facing down, insert the two M6 hex flange screws in the bottom holes on the sides of the Access Point bracket into the open slot connections on the bottom of the angle adapter bracket. AP-7562 Installation Guide...
  • Page 30 9 To adjust the position of the Access Point, rotate the Access Point bracket (plus or minus 15 degrees) and tilt the angle adapter bracket (up to 45 degrees). 10 Tighten all hex flange screws to 60 inch pounds (lbf-in). For mounting with band clamps: AP-7562 Installation Guide...
  • Page 31 AP with the gore vent. Attach (but don’t tighten) the bracket to the AP-7562 with the four M6 hex flange screws using a torque wrench, a ratchet and a 10mm socket or an adjustable wrench.
  • Page 32 3 inches. See <bl_blue><em_Emphasis>Vertical Pole Mount on page 24. 3 Attach the extension arm to the bracket (with four M6 hex flange screws) using a torque wrench, a ratchet and a 10mm socket or an adjustable wrench. The two oval holes must AP-7562 Installation Guide...
  • Page 33 Hardware Mounting and Installation be positioned on the short sides of the Access Point. Tighten the hex flange screws to 60 inch pounds (lbf-in) the unit. AP-7562 Installation Guide...

  • Page 34: Wall Mounted Installations

    For wall mount installations, use only the Access Point bracket and angle adjust bracket if required. CAUTION Always mount the AP-7562 with the black gore vent facing down. NOTE The U-bolt and band clamps are not included in the mounting bracket kit.
  • Page 35 2 Using a torque wrench or a ratchet and a 10mm socket, or an adjustable wrench, attach (but don’t tighten) the Access Point bracket to the AP-7562 with four M6 hex flange screws and insert two M6 hex flange screws into the bottom holes on the sides of the Access Point bracket.
  • Page 36 Pole Mount on page 24. 3 With the Access Point positioned so the gore vent is facing down, attach the extension arm to the Access Point bracket with two ½ inch bolts and nuts. Tighten bolts to 300 inch pounds (lbf-in). AP-7562 Installation Guide...

  • Page 37: Power Options Using Power Over Ethernet

    Product installation and mounting instructions are provided with the outdoor power injector. If located within 100 meters of the controller and a PoE port is available, the AP-7562 Access Point can also be connected directly to a WLAN or Integrated Services Controller running WiNG 5.6 or higher.
  • Page 38 Hardware Mounting and Installation AP-7562 Installation Guide...

  • Page 39: Basic Access Point Configuration

    Startup Assist or navigate to where those parameters appear in the user interface and update them accordingly. Refer to the Access Point’s more advanced configuration documentation available on the Extreme Networks support site for updating the management interface beyond the scope of the WiNG Assist configuration described in this guide.
  • Page 40 WLAN 2 both use VLAN ID 2200 by default. To adjust any of these parameters, edit the appropriate configuration screen directly. Refer to the Access Point reference material available on Extreme Networks Support for configuring the Access Point beyond the scope of the minimal WiNG Assist configuration described in this guide. For more information, go to http://documentation.extremenetworks.com...
  • Page 41 The Virtual Controller, Country Name, Timezone and Date & Time portions of the Basic Settings screen update with the settings applied and saved in the Startup Assist screen. WLAN updates made in Startup Assist are displayed in Wireless screen, not the Basic Configuration screen. AP-7562 Installation Guide...
  • Page 42 Basic Access Point Configuration AP-7562 Installation Guide...

  • Page 43: Specifications

    LED activity None indication Uplink 2 ports (GE1/GE2) auto-sensing 10/100/ 1000BaseT Ethernet; 802.3at on GE1 LAN port Antenna Connectors None Console Port Outdoor rated RJ45 console port Multi Band Security Outdoor 24x7 Wireless Intrusion Prevention Sensor System (WIPS) AP-7562 Installation Guide...

  • Page 44: Environmental Characteristics

    Electrostatic 15kV air, 8kV contact Discharge Operational Shock IEC60721-3-4, Class 4M3, MIL STD 810F Operational Vibration IEC60721-3-4, Class 4M3 Power Characteristics Operating Voltage 36-57 VDC Operating Current 375mA at 48V in 802.3at mode Integrated PoE 802.3af, 802.3at AP-7562 Installation Guide...

  • Page 45: Regulatory Information

    Regulatory Information All Extreme Networks devices are designed to be compliant with the rules and regulations in the locations they are sold and will be labeled as required. Local language translations are available at the following Website: www.extremenetworks.com/support/ Any changes or modifications to Extreme Networks equipment, not expressly approved by Extreme Networks could void the user's authority to operate the equipment.

  • Page 46: Industry Canada Statement

    Regulatory Information The available channels for 802.11bg operation in the US are Channels 1 to 11. The range of channels is limited by firmware. NOTE The EIRP for all outdoor antennas used in the 5.15 - 5.25 GHz band should not exceed a maximum 125 mW ERIP (21dBm) at any elevation angle above 30 degrees (21dBm).

  • Page 47: Rf Exposure Guidelines

    Declaration of Conformity in Languages of the European Community Hereby, Extreme Networks, Inc. declares that the radio equipment type Wireless LAN Access Point is in compliance with Directive 2014/53/EU. The full text of the EU declaration of conformity is available at the following Internet address: http://www.extremenetworks.com/...

  • Page 48: Power Supply

    Regulatory Information Power Supply This device must be powered from a 802.3af or 802.3at compliant power source which has been certified by the appropriate agencies, or by a LISTED Type no. PWRS-14000-247R or AP-PSBIAS-2P3-ATR, direct plug-in power supply, marked Class 2 or LPS (IEC60950- 1,SELV).

  • Page 49: Ce Marking And European Economic Area (Eea)

    This radio transmitter MODEL: AP-7562 has been approved by Industry Canada to operate with the antenna types listed below with the maximum permissible gain and required antenna impedance for each antenna type indicated.

  • Page 50: Statement Of Compliance

    For more information consult the website http://www.anatel.gov.br. Declarações Regulamentares para AP-7562 - Brasil Nota: A marca de certificação se aplica ao Transceptor, modelo AP-7562. Este equipamento opera em caráter secundário, isto é, não tem direito a proteção contra interferência prejudicial, mesmo de estações do mesmo tipo, e não pode causar interferência a sistemas operando em caráter primário.
  • Page 51 Regulatory Information Hong Kong In accordance with HKTA1039, the band 5.15GHz - 5.35GHz is for indoor operation only. Mexico Restrict Frequency Range to: 2.450 – 2.4835 GHz. La operación de este equipo está sujeta a las siguientes dos condiciones: (1) es posible que este equipo o dispositivo no cause interferencia perjudicial y (2) este equipo o dispositivo debe aceptar cualquier interferencia, incluyendo la que pueda causar su operación no deseada.

  • Page 52: Waste Electrical And Electronic Equipment (Weee)

    Regulatory Information Ukraine Thailand Waste Electrical and Electronic Equipment (WEEE) In accordance with Directive 2012/19/EU of the European Parliament on waste electrical and electronic equipment (WEEE): 1 The symbol above indicates that separate collection of electrical and electronic equipment is required. 2 When this product has reached the end of its serviceable life, it cannot be disposed of as unsorted municipal waste.

  • Page 53: Turkish Weee Statement Of Compliance

    Regulatory Information TURKISH WEEE Statement of Compliance EEE Yönetmeliğine Uygundur Installation Guide...
