Supported Accessories

Supported Accessories

The table below lists the accessories available for your access point. For additional information, see
802.11ax and Cloud Access Points
Note
The EIO-03-SP ships with the AP5050D.
Table 7: Available Accessories
Accessory
ACC-CAT6-LAN-GSKT
ACC-WIFI-MICRO-USB
KT-147407-02
KT-150173-01
MBO-ART02
A 10-inch Unistrut
mounting bracket with
+/- 80-degree, a 2-axis
tilt and a 7-10 inche
extension. It can be
adjusted in 10-degree
increments.
30520

AP5050D Status LED Activity Description

The access point has one status light on top of the chassis. The status light conveys operational states
for system power, firmware updates, Ethernet and wireless interface activity, and major alarms.

IQ Engine Status LED Activity

The following list shows the operational information for IQ Engine:
•
Dark: Power is Off.
•
Solid white: The device power is on and the access point is ready to use. The device has
successfully established a Control And Provisioning of Wireless Access Points (CAPWAP) connection
to ExtremeCloud IQ and is operating normally.
12 ExtremeWireless™ 802.11ax Wi-Fi 6E Outdoor AP5050D Access Point
Accessories.
Description
A black gasket.
Micro USB cable
A stainless steel hardware kit for
mounting access points outdoors.
A 12-inch extension arm for pole and
wall mounting.
A wall mounting bracket with +/-
80-degree that can be adjusted in
20-degree increments. It also has a
2-axis tilt and 10 -inch extension.
Use this bracket for outdoor use.
WS-MBO-POLE01. A pole mounting
bracket.
AP5050D Overview
Comment
For use with a CAT6 and CAT6A
cable.
Used for troubleshooting issues.
Use this bracket for outdoor use.
Use this arm when a standoff
distance is required. It provides a
minimum standoff distance of twelve
inches and helps avoid interference
with the antennas.
Use this bracket for outdoor use.
Use this bracket with MBO-ART02 for
pole mounting the MBO-ART02.
