Install the Access Point
3. Attach both the cable clamps to the WS-MBO-POLE01 bracket.
Open the cable clamp by turning a flat bladed screwdriver counterclockwise. Then insert the non-
clamp end into the pole bracket through the holes.
4. Put the metal band around the pole and attach the WS-MBO-POLE01 bracket to the pole.
5. Tighten the cable clamp screw clockwise, tightening the band around the pole.
Figure 13: Tightening the cable clamps on the POLE01 bracket

Install the Plastic Service Panel on the Access Point

About This Task
A service panel must be installed when the access point is installed under-bench or on a riser.
When a service panel is installed on an access point that is mounted on a riser, the service panel bottom
must be closed. Keeping the service panel bottom open will enable debris to fill up, that can shorten the
life of the service panel.
Note
The service panel bottom opening must be closed and glued in place when not needed. The
openings can be covered with at least 0.050 inches thick plastic or metal coverings.
Install the Plastic Service Panel on the Access Point
